KV-21FE13 / 21FE13C / 21FM13 / 21FM13C
NOTE: The components identifi ed by shading and
! mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
! D519 8-719-979-84 DIODE EGP20DPKG23
! D520 8-719-404-50 DIODE MA111-TX
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-991-33 DIODE 1SS133T-77
! D605 8-719-510-53 DIODE D4SB60L-F
D610 8-719-210-21 DIODE 11EQS04-NTA1B
D611 8-719-046-74 DIODE 10ELS2N-TA1B2
D612 8-719-110-17 DIODE MTZJ-T-77-10B
D613 8-719-046-74 DIODE 10ELS2N-TA1B2
D614 8-719-046-74 DIODE 10ELS2N-TA1B2
D615 8-719-312-10 DIODE RU4AM-T3
D616 8-719-510-37 DIODE D5LC20U
D617 8-719-110-31 DIODE MTZJ-T-77-12C
D618 8-719-991-33 DIODE 1SS133T-77
D619 8-719-110-17 DIODE MTZJ-T-77-10B
D620 8-719-510-37 DIODE D5LC20U
D622 8-719-077-76 DIODE D2SB60A-F04
D623 8-719-081-70 DIODE BA159DGPPKG3
D624 8-719-991-33 DIODE 1SS133T-77
D625 8-719-991-33 DIODE 1SS133T-77
D626 8-719-046-74 DIODE 10ELS2N-TA1B2
D627 8-719-110-03 DIODE MTZJ-T-77-7.5A
D628 8-719-510-48 DIODE D1N20R-TA
D2001 8-719-070-80 DIODE LNK0120022G
D2002 8-719-110-17 DIODE MTZJ-T-77-10B
D2003 8-719-108-12 DIODE RD9.1EW-T1
D2004 8-719-921-44 DIODE MTZJ-T-77-5.1C
D2005 8-719-921-44 DIODE MTZJ-T-77-5.1C
FUSE
! F601 1-576-193-11 FUSE 6.3A/125V
(KV-21FE13/21FM13 ONLY)
! F601 1-532-506-51 FUSE 6.3A/250V
(KV-21FE13C/ 21FM13C ONLY)
FERRITE BEAD
FB501 1-410-397-21 FERRITE 1.1µH
FB502 1-410-397-21 FERRITE 1.1µH
FB503 1-410-397-21 FERRITE 1.1µH
FB600 1-412-911-11 FERRITE 0µH
FB601 1-412-911-11 FERRITE 0µH
FB602 1-412-911-11 FERRITE 0µH
FB603 1-412-911-11 FERRITE 0µH
FB604 1-412-911-11 FERRITE 0µH
FB605 1-412-911-11 FERRITE 0µH
FB606 1-412-911-11 FERRITE 0µH
FB609 1-412-911-11 FERRITE 0µH
FB610 1-412-911-11 FERRITE 0µH
IC
IC401 8-759-490-17 IC TDA7057AQ/N2
IC405 8-759-450-93 IC NJM2521M-TE1
IC406 8-759-450-93 IC NJM2521M-TE1
(KV-21FE13/21FE13C ONLY)
! IC501 8-759-700-07 IC NJM2903M-TE2
! IC502 8-759-835-98 IC AN5522
! IC601 8-749-018-39 IC STR-F6454
(KV-21FE13C/21FM13C ONLY)
! IC601 8-749-018-45 IC STR-F6454
(KV-21FE13/21FM13 ONLY)
! IC602 8-749-016-47 IC EA135-F12
IC603 8-759-653-07 IC PQ09RD21
IC604 8-759-924-12 IC LM7805CT
IC2001 8-742-212-20 HYB IC SBX3081-71
JACK
J201 1-794-118-11 JACK BLOCK, PIN 3P
(KV-21FE13/21FE13C ONLY)
J201 1-794-115-11 JACK BLOCK, PIN 2P
(KV-21FM13/21FM13C ONLY)
J202 1-794-267-11 JACK, PIN 3P
(KV-21FE13/21FE13C ONLY)
J202 1-794-266-21 JACK, PIN 2P
(KV-21FM13/21FM13C ONLY)
J401 1-568-267-21 JACK
CHIP CONDUCTOR
JR001 1-216-295-91 SHORT
JR002 1-216-295-91 SHORT
JR202 1-216-295-91 SHORT
(KV-21FE13/21FE13C ONLY)
JR403 1-216-295-91 SHORT
JR404 1-216-295-91 SHORT
(KV-21FE13/21FE13C ONLY)
JR409 1-216-295-91 SHORT
(KV-21FE13/21FE13C ONLY)
JR410 1-216-295-91 SHORT
(KV-21FE13/21FE13C ONLY)
JR412 1-216-295-91 SHORT
(KV-21FE13/21FE13C ONLY)
JR430 1-216-295-91 SHORT
JR470 1-216-295-91 SHORT
(KV-21FM13/21FM13C ONLY)
JR501 1-216-295-91 SHORT
JR502 1-216-295-91 SHORT
JR503 1-216-295-91 SHORT
JR505 1-216-295-91 SHORT
JR520 1-216-295-91 SHORT
JR521 1-216-295-91 SHORT
JR524 1-216-295-91 SHORT
