— 42 —
KV-21FE13 / 21FE13C / 21FM13 / 21FM13C
NOTE: The components identifi ed by shading and
!
mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
JR525 1-216-295-91 SHORT
JR528 1-216-295-91 SHORT
JR529 1-216-295-91 SHORT
JR2003 1-216-295-91 SHORT
COIL
L101 1-412-029-11 INDUCTOR 10µH
L102 1-412-032-11 INDUCTOR 100µH
L103 1-412-029-11 INDUCTOR 10µH
!
L501 1-409-955-11 INDUCTOR 8mH
L502 1-412-552-11 INDUCTOR 2.2mH
L503 1-406-677-11 INDUCTOR 10mH
L504 1-412-533-21 INDUCTOR 47µH
!
L508 1-406-981-21 INDUCTOR 470µH
!
L510 1-412-528-11 INDUCTOR 18µH
L603 1-412-529-11 INDUCTOR 22µH
L604 1-412-525-31 INDUCTOR 10µH
L605 1-412-529-11 INDUCTOR 22µH
PHOTO COUPLER
!
PH601 8-749-010-64 PHOTO COUPLER PC123FY2
IC LINK
!
PS401 1-576-336-21 LINK, IC
TRANSISTOR
Q101 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q411 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
!
Q501 8-729-140-50 TRANSISTOR 2SC3209LK-TP
!
Q502 8-729-051-69 TRANSISTOR 2SD2624
!
Q503 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
!
Q504 8-729-053-87 TRANSISTOR KTC4370A
!
Q505 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
!
Q506 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
!
Q507 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q604 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
!
Q605 8-729-046-40 TRANSISTOR 2SK2663
Q606 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q607 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q608 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q609 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R101 1-216-073-91 RES-CHIP 10K 5% 1/10W
R103 1-216-295-91 SHORT
(KV-21FM13/21FM13C ONLY)
R105 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(KV-21FE13/21FE13C ONLY)
R105 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
(KV-21FM13/21FM13C ONLY)
R107 1-216-025-11 RES-CHIP 100 5% 1/10W
R108 1-216-025-11 RES-CHIP 100 5% 1/10W
R114 1-216-295-91 SHORT
(KV-21FM13/21FM13C ONLY)
R115 1-216-295-91 SHORT
(KV-21FE13/21FE13C ONLY)
R204 1-216-081-00 RES-CHIP 22K 5% 1/10W
R205 1-216-085-91 RES-CHIP 33K 5% 1/10W
R206 1-216-295-91 SHORT
(KV-21FM13/21FM13C ONLY)
R208 1-215-924-00 METAL OXIDE 15K 5% 3W
R214 1-216-113-00 RES-CHIP 470K 5% 1/10W
(KV-21FE13/21FE13C ONLY)
R215 1-216-113-00 RES-CHIP 470K 5% 1/10W
R235 1-216-113-00 RES-CHIP 470K 5% 1/10W
R237 1-216-033-00 RES-CHIP 220 5% 1/10W
R238 1-216-033-00 RES-CHIP 220 5% 1/10W
R239 1-216-113-00 RES-CHIP 470K 5% 1/10W
R409 1-216-295-91 SHORT
(KV-21FM13/21FM13C ONLY)
R421 1-249-425-11 CARBON 4.7K 5% 1/4W
R422 1-249-389-11 CARBON 4.7 5% 1/4W
R424 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R425 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(KV-21FE13/21FE13C ONLY)
R425 1-216-295-91 SHORT
(KV-21FM13/21FM13C ONLY)
R427 1-249-409-11 CARBON 220 5% 1/4W
R428 1-216-033-00 RES-CHIP 220 5% 1/10W
R436 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R437 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R438 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R439 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R443 1-216-033-00 RES-CHIP 220 5% 1/10W
R444 1-216-033-00 RES-CHIP 220 5% 1/10W
R445 1-216-073-91 RES-CHIP 10K 5% 1/10W
R447 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R450 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
(KV-21FE13/21FE13C/21FM13 ONLY)
R453 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
(KV-21FE13/21FE13C/21FM13 ONLY)
R454 1-216-025-11 RES-CHIP 100 5% 1/10W
R501 1-247-843-11 CARBON 3.3K 5% 1/4W
!
R502 1-215-892-11 METAL OXIDE 1K 5% 2W
!
R503 1-249-426-11 CARBON 5.6K 5% 1/4W
!
R506 1-215-886-11 METAL OXIDE 100 5% 2W
!
R507 1-260-320-11 CARBON 220 5% 1/2W
R508 1-249-433-11 CARBON 22K 5% 1/4W
!
R509 1-215-892-11 METAL OXIDE 1K 5% 2W
R510 1-249-411-11 CARBON 330 5% 1/4W
