— 43 —
KV-21FE13 / 21FE13C / 21FM13 / 21FM13C
NOTE: The components identifi ed by shading and
! mark are critical for safety. Replace only with
part number specifi ed.
A component identifi ed by this X symbol indicates that it
has been carefully factory-selected to satisfy regulations
regarding X-ray radiation. Should replacement be required,
replace only with the value originally used.
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
! R513 1-215-913-11 METAL OXIDE 220 5% 3W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-425-11 CARBON 4.7K 5% 1/4W
R518 1-249-427-11 CARBON 6.8K 5% 1/4W
R519 1-249-427-11 CARBON 6.8K 5% 1/4W
! R520 1-215-861-00 METAL OXIDE 47 5% 1W
! R521 1-249-411-11 CARBON 330 5% 1/4W
R522 1-249-415-11 CARBON 680 5% 1/4W
R523 1-216-073-91 RES-CHIP 10K 5% 1/10W
R524 1-249-429-11 CARBON 10K 5% 1/4W
! R525 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R526 1-208-814-91 METAL CHIP 22K 0.50% 1/10W
R527 1-216-081-00 RES-CHIP 22K 5% 1/10W
R528 1-249-421-11 CARBON 2.2K 5% 1/4W
R529 1-216-105-91 RES-CHIP 220K 5% 1/10W
R530 1-216-101-00 RES-CHIP 150K 5% 1/10W
R532 1-215-431-00 METAL 2.7K 1% 1/4W
R533 1-215-461-00 METAL 47K 1% 1/4W
R534 1-215-455-00 METAL 27K 1% 1/4W
R535 1-249-441-11 CARBON 100K 5% 1/4W
! R536 1-216-355-11 METAL OXIDE 3.3 5% 1W
! R538 1-215-890-11 METAL OXIDE 470 5% 2W
! R539 1-249-385-11 CARBON 2.2 5% 1/4W
R540 1-249-425-11 CARBON 4.7K 5% 1/4W
R541 1-249-429-11 CARBON 10K 5% 1/4W
! R542 1-215-910-00 METAL OXIDE 68 5% 3W
R543 1-247-887-00 CARBON 220K 5% 1/4W
R544 1-260-312-11 CARBON 47 5% 1/2W
! R546 1-249-377-11 CARBON 0.47 5% 1/4W
! R547 1-215-892-11 METAL OXIDE 1K 5% 2W
! R549 1-260-288-11 CARBON 0.47 5% 1/2W
! R550 1-260-288-11 CARBON 0.47 5% 1/2W
! R552 1-215-910-00 METAL OXIDE 68 5% 3W
! R553 1-216-365-00 METAL OXIDE 0.47 5% 2W
! R554 1-249-429-11 CARBON 10K 5% 1/4W
! R555 1-247-895-91 CARBON 470K 5% 1/4W
! R556 1-249-416-11 CARBON 820 5% 1/4W
! R557 1-247-895-91 CARBON 470K 5% 1/4W
! R558 1-216-097-11 RES-CHIP 100K 5% 1/10W
! R559 1-216-073-91 RES-CHIP 10K 5% 1/10W
! R560 1-215-879-11 METAL OXIDE 47K 5% 1W
! R561 1-215-416-00 METAL 620 1% 1/4W
!X R562 1-208-806-11 METAL CHIP 10K 0.50% 1/10W
! R563 1-215-469-00 METAL 100K 1% 1/4W
! R565 1-249-429-11 CARBON 10K 5% 1/4W
! R566 1-216-073-91 RES-CHIP 10K 5% 1/10W
! R567 1-216-073-91 RES-CHIP 10K 5% 1/10W
! R568 1-215-882-00 METAL OXIDE 22 5% 2W
R571 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R572 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
! R601 1-219-513-11 CARBON 4.7M 5% 1/2W
(KV-21FE13/21FM13 ONLY)
! R602 1-249-389-11 CARBON 4.7 5% 1/4W
R603 1-215-485-00 METAL 470K 1% 1/4W
! R605 1-205-998-11 CEMENTED 1 5% 10W
(KV-21FE13/21FM13 ONLY)
! R605 1-202-968-11 CEMENTED 1.2 5% 10W
(KV-21FE13C/21FM13C ONLY)
! R606 1-205-998-11 CEMENTED 1 5% 10W
(KV-21FE13/21FM13 ONLY)
! R606 1-202-968-11 CEMENTED 1.2 5% 10W
(KV-21FE13C/21FM13C ONLY)
R607 1-215-859-00 METAL OXIDE 22 5% 1W
R608 1-240-205-11 CARBON 22M 5% 1/2W
R609 1-216-049-11 RES-CHIP 1K 5% 1/10W
R610 1-216-073-91 RES-CHIP 10K 5% 1/10W
R611 1-216-089-91 RES-CHIP 47K 5% 1/10W
R612 1-216-045-00 RES-CHIP 680 5% 1/10W
! R613 1-219-512-11 CARBON 2.2M 5% 1/2W
R614 1-249-413-11 CARBON 470 5% 1/4W
! R615 1-218-265-11 METAL 8.2M 5% 1W
(KV-21FE13C/21FM13C ONLY)
! R616 1-260-302-51 CARBON 6.8 5% 1/2W
R617 1-216-009-91 RES-CHIP 22 5% 1/10W
! R621 1-202-968-11 CEMENTED 1.2 5% 10W
(KV-21FE13C/21FM13C ONLY)
! R626 1-220-926-11 FUSIBLE 0.47 10% 1/2W
R627 1-215-483-00 METAL 390K 1% 1/4W
(KV-21FE13/21FM13 ONLY)
R627 1-215-479-00 METAL 270K 1% 1/4W
(KV-21FE13C/21FM13C ONLY)
R628 1-215-479-00 METAL 270K 1% 1/4W
(KV-21FE13C/21FM13C ONLY)
R630 1-249-421-11 CARBON 2.2K 5% 1/4W
! R632 1-216-361-00 METAL OXIDE 0.22 5% 2W
R633 1-249-415-11 CARBON 680 5% 1/4W
R634 1-216-073-91 RES-CHIP 10K 5% 1/10W
R635 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
! R637 1-216-485-11 METAL OXIDE 5.6K 5% 3W
(KV-21FE13C/21FM13C ONLY)
R638 1-249-399-11 CARBON 33 5% 1/4W
(KV-21FE13/21FM13 ONLY)
R638 1-249-402-11 CARBON 56 5% 1/4W
(KV-21FE13C/21FM13C ONLY)
R639 1-249-421-11 CARBON 2.2K 5% 1/4W
R640 1-249-417-11 CARBON 1K 5% 1/4W
! R641 1-216-363-00 METAL OXIDE 0.33 5% 2W
R642 1-216-089-91 RES-CHIP 47K 5% 1/10W
