MC-S50
Pin No. Pin Name I/O
Description
96 X1
O System clock output terminal (16.9344MHz)
97 X2/CLKIN
I System clock input terminal (16.9344MHz)
98 RS
I Reset signal input to the CPU (IC801) “L”: reset
99 to 104 D0 to D5
I/O Two-way data bus with the flash ROM (IC602) and USB controller (IC901)
105 A16
— Address signal terminal Not used (open)
106 DVSS
— Ground terminal
107 to 11
0
A17 to A20
— Address signal terminal Not used (open)
111 CVSS
— Ground terminal
112 DVDD
— Power supply terminal (+3.2V)
113, 114 D6, D7
I/O Two-way data bus with the flash ROM (IC602) and USB controller (IC901)
115 to 119 D8 to D12
I/O Two-way data bus Not used (open)
120 HD4
O Chip select signal output to the flash ROM (IC602)
121 to 123 D13 to D15
I/O Two-way data bus Not used (open)
124 HD5
O Audio system power ON/OFF control signal output terminal “H”: ON
125 CVDD —
Power supply terminal (+1.5V)
126 CVSS
— Ground terminal
127 HDS1
I Data signal input terminal Not used (fixed at “H”)
128 DVSS
— Ground terminal
129 HDS2
I Data signal input terminal Not used (fixed at “H”)
130 DVDD
— Power supply terminal (+3.2V)
131 to 13
4
A0 to A3
O Address signal output to the USB controller (IC901)
135 HD6
O Reset signal output to the D/A converter (IC302) “L”: reset
136 to 139 A4 to A7
O Address signal output to the USB controller (IC901)
140, 141 A8, A9
— Address signal terminal Not used (open)
142 CVDD —
Power supply terminal (+1.5V)
143 A21
— Address signal terminal Not used (open)
144 DVSS
— Ground terminal
