MDX-F5800
13
3-5. SERVO BOARD
3-4. MAIN BOARD
1
three screws
(BTT2.6
×
5)
2
four screws
(PTT2.6
×
6)
3
main board
2
four screws
(BVTT2
×
4)
1
optical pick-up flexible board
(CN2)
1
parallel (FFC) (10core) wir
e
(CN3)
3
servo board
