MDX-F5800
11
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
FRONT PANEL ASSY
(Note 3)
3-8. LEVER (LE23) ASSY
(Page 15)
3-9. HOLDER ASSY
(Page 15)
3-10. CHUCKING ARM ASSY
(Page 16)
3-11. OPTICAL PICK-UP (KMS-242E)
(Page 16)
3-12. SL MOTOR ASSY (SLED) (M902),
SP MOTOR ASSY (SPINDLE) (M901)
(Page 17)
3-2. SUB PANEL ASSY
(Page 12)
3-3. MECHANISM DECK (MG-165A-138)
(Page 12)
3-4. MAIN BOARD
(Page 13)
3-5. SERVO BOARD
(Page 13)
3-6. MD COVER ASSY
(Page 14)
3-7. FLOAT BLOCK
(Page 14)
SET
Note 1: The process described in can be performed in any order.
Note 2: Without completing the process described in , the next process can not be performed.
Note 3: Illustration of disassembly is omitted.
To Next Page
