8
GB
1 Connect the front speakers.
Connect the right and left speaker cords to
the FRONT SPEAKER jacks as shown
below.
2 Connect the surround speakers.
(Except for MHC-RV777D)
Connect the speaker cords to the
SURROUND SPEAKER jacks as shown
below.
Main unit
Speakers (MHC-RV888D only)
Note
For MHC-RV999D, the speaker cords are attached to
the surround speakers. Connect the surround speaker
cords to the main unit only.
3 Connect the center speaker.
(Except for MHC-RV777D)
Connect the speaker cords to the CENTER
SPEAKER jacks as shown below.
4 Connect the sub woofer.
(MHC-RV999D only)
Connect the audio cord to the SUB
WOOFER OUT jack on the unit and the
INPUT jack on the sub woofer as shown
below.
For details on using the sub woofer, see
“Using the sub woofer” on page 44.
Main unit
Sub woofer
+
Black/Stripe (#)
Gray/Solid
(3)
Insert only the stripped portion
+
R
L
Gray/Solid
(3)
Black/Stripe (#)
Insert only the stripped portion
Gray/Solid (3)
Black/Stripe
(#)
+
R
L
Gray/Solid
(3)
Insert only the stripped portion
Black/Stripe (#)
SUB WOOFER OUT
INPUT
