Sony MHC-V4D Service Manual

MHC-V3/V4D
74
ARAGON BOARD (2/6) IC301 CXD9990R (CD RF AMP FOCUS/TRACKING ERROR AMP CD SYSTEM
PROCESSOR DIGITAL SERVO PROCESSOR) (V4D)
Pin No. Pin Name I/O Description
1 RF_C I RF main beam C input from the optical pick-up block
2 RF_D I RF main beam D input from the optical pick-up block
3 RF_E I RF sub beam E input from the optical pick-up block
4 RF_F I RF sub beam F input from the optical pick-up block
5 AVDD12_2 - Power supply terminal (+1.2V)
6 AVDD33_1 - Power supply terminal (+3.3V)
7 XTALI I System clock input terminal (27 MHz)
8 XTALO O System clock output terminal (27 MHz)
9 AGND33 - Ground terminal
10 V20 O Reference voltage (+2V) output to the optical pick-up block
11 V14/VREF0 O Reference voltage (+1.4V) output terminal
12 REXT I Current reference input terminal Fixed at “L” in this set
13 MDI1 I Laser power monitor input from the optical pick-up block
14 LDO1 O Laser diode drive signal output to the optical pick-up block
15 LDO2 O Laser diode drive signal output to the optical pick-up block
16 AVDD33_2 - Power supply terminal (+3.3V)
17 DMO O Spindle motor control signal output to the motor driver
18 FMO O Sled motor control signal output to the motor driver
19 CD_VR O Muting signal output to the coil/motor driver (for spindle motor)
20 DVD_VR O CD/DVD selection signal output terminal “L”: CD, “H”: DVD
21 TRO O Tracking coil control signal output to the coil driver
22 FOO O Focus coil control signal output to the coil driver
23 MSW I Thermal shut down signal input from the coil/motor driver
24 USB_DM I/O Two-way audio serial data with the USB controller
25 USB_DP I/O Two-way audio serial data with the USB controller
26 VDD33_USB - Power supply terminal (+3.3V)
27 VSS33_USB - Ground terminal
28 PAD_VRT I/O USB generating reference current terminal
29 VDD12_USB - Power supply terminal (+1.2V)
30 SF_CS# O Chip select signal output to the fl ash ROM
31 SF_DO O Serial data output to the fl ash ROM
32 SF_DI I Serial data input from the fl ash ROM
33 SF_CK O Serial clock signal output to the fl ash ROM
34 IFSCK O Serial data transfer clock signal output to the system controller
35 IFSDO O Serial data output to the system controller
36 RX - Not used
37 TX - Not used
38 PRST# I Reset signal input from the system controller “L”: reset
39 NC I IR control signal input terminal Not used
40 IFSDI I Serial data input from the system controller
41 IFBSY I Communication initialization request signal input from the system controller
42 IFCS# O Communication initialization request acknowledge signal output to the system controller
43 MFISW - Not used
44 LIMITSW - Not used
45 MUTE O Muting signal output to the coil/motor driver (for focus/tracking coil and sled motor)
46 EEWP - Not used
47 SDA - Not used
48 SCL - Not used
49 NC - Not used
50 DVSS33 - Ground terminal
51 DVDD33 - Power supply terminal (+3.3V)
52 to 55 RD0 to RD3 I/O Two-way data bus with the SD-RAM
56 DVDD12 - Power supply terminal (+1.2V)
57 to 60 RD4 to RD7 I/O Two-way data bus with the SD-RAM
Ver. 1.1

Sony MHC-V4D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Bass reflex	-
Speaker type	3-way
RMS rated power	720 W
Woofer diameter	200 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
Equalizer modes	Custom, Pop, Flat, Rap, Rock
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Composite video out	1
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	English
Playback modes	Program, Shuffle, Repeat, Normal
Audio formats supported	WMA, MP3
Display type	LCD

Weight and Dimensions

Depth	295 mm
Width	280 mm
Height	780 mm
