Sony MHC-V4D - Loading Panel Section

77
MHC-V3/V4D
7-2. LOADING PANEL SECTION
51 X-2589-368-1 PANEL, LOADING ASSY
52 4-536-754-01 SPRING (LP)
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
#2 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark
Ver. 1.5
#1
#2
#2
top panel section
51
52
A
A
not supplied
not supplied
not
supplied
not
supplied
not supplied
CDM block section
back panel section
(V4D)
