Appendix
A-2 Appendix
Specifications
Recommended tapes
MPEG IMX cassettes (S, L):
BCT-6MX/12MX/22MX/32MX/
60MX
BCT-64MXL/94MXL/124MXL/
184MXL
Digital Betacam cassettes (S, L)
(for playback only) (MSW-
M2000/M2000P/M2000E/
M2000EP)
Betacam SX cassettes (S, L) (for
playback only)
Betacam SP cassettes (S, L) (for
playback only)
Betacam cassettes (S, L) (for
playback only) (MSW-M2000/
M2000P/M2000E/M2000EP)
Digital video system
Digital video signal system
Sampling frequency
Y: 13.5 MHz
R–Y/B–Y: 6.75 MHz
Quantization 8 bits/sample
Compression MPEG2 4:2:2P@ML
Channel coding S-I-NRZI PR-IV
Error correction Reed-Solomon code
Analog component output
Bandwidth
Y0 to 5.75 MHz +0.5 dB/–2.0 dB
R–Y/ B–Y 0 to 2.75 MHz +0.5 dB/–2.0 dB
S/N ratio 56 dB or more
K factor (2T pulse)
1% or less
Analog component input to analog
component output
Input A/D quantization
10 bits/ sample
Bandwidth
Y0 to 5.75 MHz +0.5 dB/–2.0 dB
R–Y/ B–Y 0 to 2.75 MHz +0.5 dB/–2.0 dB
S/N ratio 52 dB or more
K factor (2T pulse)
1% or less
LF non-linearity 3.0% or less
Analog composite input to analog composite
output
Bandwidth (Y) 0 to 5.75 MHz +0.5 dB/ –2.0 dB
S/N ratio 53 dB or more
Differential gain 2% or less
Differential phase 2° or less
Y/C delay 20 ns or less
K factor (2T pulse)
1% or less
Output SCH phase
Based upon RS-170A/CCIR
R.624-3
(Adjustable by using the menu)
Digital audio system
Digital audio (CH1 to CH8) signal format
Sampling frequency
48 kHz (synchronized with video)
Quantization 16 bits/sample or 24 bits/sample
Wow and flutter Below measurable level
Headroom 20 dB (or 18 dB, selectable)
Emphasis T1= 50 µs, T2=15 µs (on/off
selectable in recording mode)
Analog output
A/D, D/A quantization
24 bits/sample
Frequency response
20 Hz to 20 kHz +0.5 dB/ –1.0 dB
(0 dB at 1 kHz)
Dynamic range 90 dB or more (at 1 kHz, emphasis
on, 16 bits/48 kHz)
95 dB or more (at 1 kHz, emphasis
on, 24 bits/48 kHz)
Distortion 0.05% or less (at 1 kHz, emphasis
on, reference level (+4 dBm))
Crosstalk –80 dB or less (at 1 kHz, between
any two channels)
Network system (MSW-M2000E/M2000EP
only)
MXF D10 files
Video MPEG IMX (50/40/30 Mbps)
Audio 16 bits/48 kHz (8 channels) or
24 bits/48 kHz (4 channels)
Proxy AV files
Video MPEG 4
(The Codec of MPEG-4 is products of
Ingenient Technologies, Inc.)
Audio A-law (8 bits/8 kHz, 8/4 channels)
