7-3. MAIN BOARD SECTION
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
101 3-237-079-01 CASE, BATTERY
102 3-237-073-01 TERMINAL BOARD (+), BATTERY
103 3-237-074-01 TERMINAL (–), BATTERY
* 104 X-3381-933-1 MAIN BOARD, COMPLETE (EXCEPT US, FR)
* 104 X-3381-967-1 MAIN BOARD, COMPLETE (US)
* 104 X-3382-202-1 MAIN BOARD, COMPLETE (FR)
101
102
103
104
