11
MZ-S1
3-6. SET CHASSIS ASSY
3-7. MAIN BOARD
2
two screws
(1.7
×
2.5)
3
set chassis ass
y
1
four screws
(M1.4
×
2)
3
battery case
4
main board
2
battery terminal (–)
1
battery terminal board (+)
