9
MZ-S1
3-3. BUCKLE (UPPER) ASSY, BATTERY CASE LID
4
Open the battery
case lid.
7
buckle (lower)
1
two screws
(1.7)
1
two screw
s
(1.7)
5
6
6
3
four screws
(M1.4)
2
four spacers (DC in)
9
buckle (upper) assy
8
boss
8
boss
qa
battery case lid
0
shaft (battery case lid)
qs
plate (lower)
