Sony MZ-S1 - Page 63

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
63
MZ-S1
MAIN
C612 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C613 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C614 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C615 1-137-760-11 CAP-CHIP 100PF 5% 100V
C616 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C618 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C619 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C621 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C622 1-131-862-11 TANTALUM CHIP 47uF 20% 4V
C624 1-115-169-11 TANTALUM 10uF 20% 6.3V
C625 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C627 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C628 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C629 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C630 1-128-829-11 TANTALUM CHIP 220uF 20% 6.3V
C632 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C633 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C634 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C638 1-128-829-11 TANTALUM CHIP 220uF 20% 6.3V
C639 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C701 1-137-739-11 TANTALUM 22uF 20% 6.3V
C702 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C703 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C704 1-137-934-11 TANTALUM CHIP 47uF 20% 10V
C801 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C802 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C803 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C804 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C805 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C806 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C807 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C808 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C809 1-137-739-11 TANTALUM 22uF 20% 6.3V
C810 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C811 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C812 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C813 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C814 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C815 1-110-569-11 TANTALUM CHIP 47uF 20% 6.3V
C816 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C817 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C818 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C819 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C820 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C821 1-137-740-11 TANTALUM 47uF 20% 6.3V
C822 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C823 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C824 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C825 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C826 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C828 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C829 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C830 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C832 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C833 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C834 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C838 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C839 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C840 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C841 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C901 1-165-851-11 TANTALUM CHIP 10uF 20% 6.3V
C902 1-165-851-11 TANTALUM CHIP 10uF 20% 6.3V
C903 1-128-964-11 TANTALUM CHIP 100uF 20% 6.3V
C904 1-119-750-11 TANTALUM CHIP 22uF 20% 6.3V
C905 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C906 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C907 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C908 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C909 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C910 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C911 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C912 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C913 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C914 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C915 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C916 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C917 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C918 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C919 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C920 1-117-919-11 TANTALUM CHIP 10uF 20% 6.3V
C921 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C922 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C924 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C926 1-115-169-11 TANTALUM 10uF 20% 6.3V
C927 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C928 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN501 1-573-360-21 CONNECTOR, FFC/FPC 20P
CN502 1-573-350-11 CONNECTOR, FFC/FPC 10P
CN701 1-816-036-21 CONNECTOR (SQUARE TYPE) (USB) 5P
(USB CONNECTOR)
CN802 1-750-862-21 PIN, CONNECTOR (PC BOARD) 5P
CN803 1-573-352-11 CONNECTOR, FFC/FPC 12P
< DIODE >
D101 8-719-056-72 DIODE UDZ-TE-17-2.4B
D201 8-719-056-72 DIODE UDZ-TE-17-2.4B
D601 8-719-081-33 DIODE MA2YD1500LS0
D602 8-719-081-33 DIODE MA2YD1500LS0
D603 8-719-081-33 DIODE MA2YD1500LS0
D606 8-719-081-35 DIODE MA2YD1700LS0
D607 8-719-081-33 DIODE MA2YD1500LS0
D608 8-719-081-35 DIODE MA2YD1700LS0
D701 8-719-421-28 DIODE MA728-TX
D703 8-719-081-33 DIODE MA2YD1500LS0
D803 8-719-017-58 DIODE MA8068-TX
D804 8-719-420-51 DIODE MA729-TX
D901 8-719-081-33 DIODE MA2YD1500LS0
D902 8-719-081-33 DIODE MA2YD1500LS0
D903 8-719-420-51 DIODE MA729-TX
D904 8-719-404-50 DIODE MA111-TX
< RESISTOR >
FB701 1-216-864-11 METAL CHIP 0 5% 1/16W
