Sony PCM-D50 - Page 47

PCM-D50
47
IC3404 AK4114VQ-L (AD Board (2/3))
IC3405 TC7PA53FU(TE85L.F) (AD Board (2/3))
IC3406 TC7PA53FU(TE85L.F) (AD Board (2/3))
IC3407 TC7PA53FU(TE85L.F) (AD Board (2/3))
1
IPS0/RX4
CLOCK
RECOVERY
48 47 46 45 44 43 42 41 40 39 38 37
36
INT0
35OCKS0/CSN/CAD0
34
OCKS1/CCLK/SCL
33
CM1/CDTI/SDA
32
CM0/CDTO/CAD1
2
AVSS
3DIF0/RX5
4
TEST2
5
DIF1/RX6
6AVSS
7
DIF2/RX7
8
IPS1/IIC
9
P/SM
10XTL0
11
XTL1
12
VIN
AC_3/MPEG
DETECT
CLOCK
GENERATOR
AUDIO
I/F
Q-SUBCODE
BUFFER
DIT
DEM
X’tal
OSC
DIAF
DECODER
ERROR &
STATUS
DETECT
I/F
31
PDN
30
XTI
29
XTO
28
DAUX
27
MCK02
26
BICK
25
23 24151413
SDTO
16 17 18 19 20 21 22
1
6
B2
S
5
VCC
4
A
2GND
3
B1
