10
RCD-W500C
3-8. Motor Assy (Loading) (M201)
3-7. CDR Board
7
c
law
6
c
law
8
c
onnector
(2pin) (CN104)
3
flexible flat cable
(32core) (CN101)
4
flexible flat cable
(11core) (CN102)
5
flexible flat cable
(11core) (CN103)
9
CDR board
2
bottom plate
1
four
screws
(+BVTP 2.6
×
8)
1
Slide the cam (CH) to the direction of arrow.
2
Remove the belt (loading) from the
pulley of the motor assy.
3
t
wo claws
4
m
otor assy
(loading) (M201)
