7373
RCD-W500C
6-16. Printed Wiring Boards – Led Section – • See page 55 for Circuit Boards Location.
• : Uses unleaded solder.
IC750
Ref. No. Location
D751 B-2
D752 B-3
D753 B-4
D754 B-5
D755 B-6
IC750 B-7
Q780 B-7
• Semiconductor
Location
