RCD-W500C
SECTION 3
DISASSEMBLY
Note : • Disassemble the unit in the order as shown below.
•This set can be disassemble according to the following sequence.
The dotted square with arrow ( ) prompts you to move to the next job when all of the works within the dotted square ( )
are completed.
MOTOR ASSY
(LOADING) (M201)
OPTICAL PICK-UP
(KRM-220CAA)
CAM (CH)
LOADING PANEL (CDR)
CD MECHANISM DECK
(CDM53L-30B61M)
CD MECHANISM DECK
(CDM65-RBD2)
FITTING BASE
(MAGNET) ASSY
FITTING BASE (GUIDE) ASSY,
BRACKET (CHASSIS)
LOAD MOTOR BOARD,
MOTOR (LOADING) ASSY
STOCKER SECTION
GEAR (GEAR A),
GEAR (GEAR B),
GEAR(U/D SLIDER)
GEAR (CHUCKING)
SLIDER (SELECTION),
TENSION SPRING (SHUTTER),
SLIDER (SHUTTER)
TRAY (SUB)
CHASSIS (MOLD B)
BD BOARD
OPTICAL BLOCK SECTION
CLAMP MOTOR BOARD,
MOTOR (CLAMP) ASSY
SW BOARD, LED BOARD,
DISP BOARD
CDR BOARD
HOLDER (MG) SUB ASSY,
DUST COVER
TRAY
MAIN BOARD
CASE (409538)
FRONT PANEL SECTION
SET
