9
RCD-W500C
3-5. CD Mechanism Deck (CDM65-RBD2)
3-6. Tray
3
four
screws (+BVTP 3
×
8)
2
wire (flat type)
(11core) (CN630
)
1
connector
(4pin) (CN111)
4
CDR mechanism deck
(CDM65-RBD2)
1
Slide the lever (cam (CH)) to the direction of arrow.
4
t
ray
2
Pull the tray while pressing the claw of
the chassis in the direction of the arrow.
3
Pull the tray while pressing the claw of the chassis and the claw
of the tray in the direction of the arrow.
front panel side
lever (cam (CH))
claw
claw
chassis
chassis
