Sony RMT-V501D - VCR Mechanical Parts (Bottom Side)

8-4
8-1-3 VCR Mechanical Parts (Bottom Side)
G542
B462
B560
B570
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not
supplied
not supplied
not supplied
not supplied
B462 3-075-260-01 SCREW MAC 3X3
B560 9-885-060-94 MOTOR CAPSTAN
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
B570 9-885-061-03 SCREW CAP 2.6X6
G542 3-078-583-01 BELT RECTANGULAR
