Sony RMT-V501D - Tray Disc Removal

2-23
2-6-2 Tray Disc Removal
1) Insert a Screw Driver 1 into Emergency Hole 2 and push the Slider Housing 3 in the direction arrow “A”.
2) When the Tray Disc 4 comes out a little, pull it in the direction arrow “B” by hand.
Fig. 2-45 Tray Disc Removal
"B"
3 SLIDER HOUSING
4 TRAY DISC
"A"
1 SCREW DRIVER
2 EMERGENCY HOLE
