Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT770
63
R829 1-250-656-11 METAL CHIP 47K 1% 1/10W
R830 1-216-833-11 METAL CHIP 10K 5% 1/10W
R831 1-216-837-11 METAL CHIP 22K 5% 1/10W
R832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R833 1-216-864-11 SHORT CHIP 0
************************************************************
9 A-2041-183-A HDMI BOARD, COMPLETE (for SERVICE)
********************
< CAPACITOR >
* C3008 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3014 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3015 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C3021 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C3027 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3028 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3029 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3030 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3033 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3037 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3040 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3048 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C3049 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C3054 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C3055 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
* C3056 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3057 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C3058 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C3059 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3060 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C3061 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3063 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C3064 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C3066 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3067 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3068 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C3069 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C3073 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3074 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3075 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3076 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3077 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3080 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3081 1-116-724-11 CERAMIC CHIP 4.7uF 20% 6.3V
C3084 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C3085 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C3086 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C3087 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
* C3098 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3099 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3102 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3106 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
* C3108 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3109 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3111 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
* C3112 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN3000 1-821-398-41 HDMI CONNECTOR (HDMI IN 1) (Type B)
(Except US, CND) (See Note 1)
CN3000 1-843-486-21 HDMI CONNECTOR (HDMI IN 1) (Type A)
(See Note 1)
CN3001 1-821-398-41 HDMI CONNECTOR (HDMI IN 2) (Type B)
(Except US, CND) (See Note 1)
CN3001 1-843-486-21 HDMI CONNECTOR (HDMI IN 2) (Type A)
(See Note 1)
CN3002 1-821-398-41 HDMI CONNECTOR (HDMI IN 3) (Type B)
(Except US, CND) (See Note 1)
CN3002 1-843-486-21 HDMI CONNECTOR (HDMI IN 3) (Type A)
(See Note 1)
CN3005 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN3006 1-821-398-41 HDMI CONNECTOR (TV (ARC) HDMI OUT)
(Type B) (Except US, CND) (See Note 1)
CN3006 1-843-486-21 HDMI CONNECTOR (TV (ARC) HDMI OUT)
(Type A) (See Note 1)
CN3009 1-820-117-41 CONNECTOR, FFC/FPC 19P
< DIODE >
D3001 6-503-738-01 DIODE CES521
D3003 8-719-053-18 DIODE 1SR154-400TE-25
D3004 8-719-053-18 DIODE 1SR154-400TE-25
< LUG TERMINAL >
* ET3000 1-780-408-11 TERMINAL, LUG
* ET3001 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB3002 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB3003 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3004 1-400-921-21 FERRITE, EMI (SMD)
FB3005 1-481-348-21 EMI FERRITE (SMD) (1608)
< IC >
IC3002 6-719-139-01 IC MM3411A50NRE
IC3005 6-717-680-01 IC BD00IC0WEFJ-E2
IC3006 6-717-680-01 IC BD00IC0WEFJ-E2
IC3007 6-718-999-01 IC MM1839A50NRE
IC3009 (Not supplied) IC SII9535CTUC (See Note 2)
< COIL >
L3000 1-469-525-91 INDUCTOR 10uH
L3006 1-412-977-41 INDUCTOR 0.68uH
< RESISTOR >
R3000 1-218-990-81 SHORT CHIP 0
R3001 1-218-990-81 SHORT CHIP 0
R3002 1-218-990-81 SHORT CHIP 0
R3003 1-218-933-11 METAL CHIP 22 5% 1/16W
R3004 1-218-933-11 METAL CHIP 22 5% 1/16W
R3005 1-218-933-11 METAL CHIP 22 5% 1/16W
R3006 1-218-933-11 METAL CHIP 22 5% 1/16W
R3007 1-218-933-11 METAL CHIP 22 5% 1/16W
R3008 1-218-933-11 METAL
CHIP 22 5% 1/16W
R3009 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3010 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3011 1-216-864-11 SHORT CHIP 0
R3023 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3034 1-218-969-11 METAL CHIP 22K 5% 1/16W
R3036 1-218-953-11 METAL CHIP 1K 5% 1/16W
Note 1: Refer to the “NOTE OF REPLACING THE PARTS ON
THE HDMI BOARD” on page 4 for how to distinguish
type of parts. (Except US and Canadian models only)
Note 2: IC3009 on the HDMI board cannot replace with
single. When this part is damaged, replace the
complete mounted board.
Ver. 1.1
DISPLAY
HDMI
