Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT770
64
R3037 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3055 1-216-864-11 SHORT CHIP 0
R3062 1-216-864-11 SHORT CHIP 0
R3076 1-216-864-11 SHORT CHIP 0
R3082 1-216-864-11 SHORT CHIP 0
R3087 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3088 1-218-941-81 METAL CHIP 100 5% 1/16W
* R3089 1-250-523-11 METAL CHIP 15K 1% 1/16W
R3090 1-250-535-11 METAL CHIP 47K 1% 1/16W
R3091 1-218-941-81 METAL CHIP 100 5% 1/16W
R3092 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3093 1-218-941-81 METAL CHIP 100 5% 1/16W
R3094 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3095 1-218-990-81 SHORT CHIP 0
R3098 1-218-990-81 SHORT CHIP 0
R3099 1-220-168-81 METAL CHIP 62 5% 1/16W
R3100 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3101 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3102 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3103 1-218-933-11 METAL CHIP 22 5% 1/16W
R3104 1-218-933-11 METAL CHIP 22 5% 1/16W
R3105 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R3106 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R3112 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3113 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3114 1-218-937-11 METAL CHIP 47 5% 1/16W
R3115 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R3116 1-218-941-81 METAL CHIP 100 5% 1/16W
R3128 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3129 1-216-797-11 METAL CHIP 10 5% 1/10W
R3131 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3132 1-216-797-11 METAL CHIP 10 5% 1/10W
R3135 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3136 1-220-208-81 METAL CHIP 130K 5% 1/16W
R3148 1-216-864-11 SHORT CHIP 0
R3150 1-216-864-11 SHORT CHIP 0
R3160 1-218-937-11 METAL CHIP 47 5% 1/16W
R3161 1-218-937-11 METAL CHIP 47 5% 1/16W
R3162 1-218-937-11 METAL CHIP 47 5% 1/16W
R3163 1-218-937-11 METAL CHIP 47 5% 1/16W
R3164 1-218-937-11 METAL CHIP 47 5% 1/16W
R3172 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3173 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3174 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3175 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3183 1-218-990-81 SHORT CHIP 0
R3184 1-218-937-11 METAL CHIP 47 5% 1/16W
R3185 1-216-813-11 METAL CHIP 220 5% 1/10W
R3187 1-218-941-81 METAL CHIP 100 5% 1/16W
R3188 1-218-941-81 METAL CHIP 100 5% 1/16W
R3189 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3190 1-216-797-11 METAL CHIP 10 5% 1/10W
R3191 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3193 1-216-864-11 SHORT CHIP 0
R3194 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3195 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3196 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3197 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3200 1-218-937-11 METAL CHIP 47 5% 1/16W
R3201 1-218-945-11 METAL CHIP 220 5% 1/16W
R3202 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3203 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R3204 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R3205 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R3206 1-218-990-81 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB3000 1-234-400-21 CONDUCTOR, NETWORK (1005X4) (Type B)
(Except US, CND) (See Note)
RB3000 1-457-539-11 COMMON MODE CHOKE COIL (Type A)
(See Note)
RB3001 1-234-400-21 CONDUCTOR, NETWORK (1005X4) (Type B)
(Except US, CND) (See Note)
RB3001 1-457-539-11 COMMON MODE CHOKE COIL (Type A)
(See Note)
< VIBRATOR >
X3001 1-814-595-11 QUARTS CRYSTAL UNIT (27 MHz)
*************************************************************
A-1979-511-A IO BOARD, COMPLETE
******************
< CAPACITOR >
C201 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C202 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
* C203 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
* CN201 1-760-388-11 CONNECTOR PIN (SMD) 9P
< IC >
IC201 6-600-827-01 IC JSR1124 (OPT (TV) DIGITAL IN)
< JACK >
J201 1-566-822-61 JACK (ANALOG IN)
< RESISTOR >
R201 1-216-864-11 SHORT CHIP 0
R202 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R203 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R204 1-218-941-81 METAL CHIP 100 5% 1/16W
*************************************************************
IR BOARD
********
< CAPACITOR >
* C901 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
< CONNECTOR >
CN901 1-580-056-21 PIN, CONNECTOR (SMD) 3P
< IC >
IC901 6-600-780-01 IC PNA4823M05S0
< RESISTOR >
R901 1-216-805-11 METAL CHIP 47 5% 1/10W
R902 1-216-805-11 METAL CHIP 47 5% 1/10W
*************************************************************
Note: Refer to the “NOTE OF REPLACING THE PARTS ON
THE HDMI BOARD” on page 4 for how to distinguish
type of parts. (Except US and Canadian models only)
Ver. 1.1
HDMI
IO IR
