Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT770
65
KEY BOARD
**********
< CAPACITOR >
C701 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C702 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C703 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN701 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< RESISTOR >
R701 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R702 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R703 1-216-821-11 METAL CHIP 1K 5% 1/10W
R704 1-216-821-11 METAL CHIP 1K 5% 1/10W
R705 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S701 1-786-653-11 SWITCH, TACTILE (
?
/1)
S702 1-786-653-11 SWITCH, TACTILE (PAIRING)
S703 1-786-653-11 SWITCH, TACTILE (INPUT)
S704 1-786-653-11 SWITCH, TACTILE (VOL −)
S705 1-786-653-11 SWITCH, TACTILE (VOL +)
*************************************************************
A-1989-142-A MAIN BOARD, COMPLETE (US, CND) (See Note)
A-1989-146-A MAIN BOARD, COMPLETE (AEP, UK) (See Note)
A-2046-181-A MAIN BOARD, COMPLETE (TW) (See Note)
A-2046-183-A MAIN BOARD, COMPLETE (AUS, CH, EA, SP)
(See Note)
********************
< CAPACITOR >
C1001 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1002 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1003 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1005 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1006 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1007 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C1008 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1009 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C1010 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C1011 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C1013 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C1016 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1018 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1021 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1026 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1027 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1029 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C1030 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C1031 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C1032 1-165-492-21 ELECT CHIP 100uF 20% 10V
C1033 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1034 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1035 1-165-492-21 ELECT CHIP 100uF 20% 10V
C1036 1-126-210-21 ELECT CHIP 220uF 20% 4V
* C1037 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C1038 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C1039 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
* C1040 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C1041 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C1042 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
* C1043 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C1044 1-128-992-21 ELECT CHIP 47uF 20% 25V
C1045 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1046 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1054 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C1055 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C1056 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1057 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1059 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1060 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1061 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
* C2002 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C2003 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2004 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C2005 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2006 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C2008 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2009 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2010 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2011 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2012 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2013 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2014 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C2015 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C2016 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2017 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C2018 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2019 1-118-395-11 CERAMIC CHIP 0.0047uF 10% 50V
* C2020 1-118-387-11 CERAMIC CHIP 0.068uF 10% 16V
C2021 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2022 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C2023 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C2024 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2025 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C2026 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C2027 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C2028 1-165-492-21 ELECT CHIP 100uF 20% 10V
C2029 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C2030 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2031 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2032 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2033 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2034 1-165-492-21 ELECT CHIP 100uF 20% 10V
C2035 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2036 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C2037 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C2038 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2039 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2040 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2042 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2044 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2046 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2047 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2049 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2050 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2051 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2053 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2054 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
Note: When the complete MAIN board is replaced, refer to “NOTE OF REPLACING THE
IC3001 ON THE MAIN BOARD AND THE COMPLETE MAIN BOARD” on page 4.
Ver. 1.1
