Sony SA-WCT770 - RESISTORS

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WCT770
3333
D950 8-719-080-53 DIODE RK36LF-B3
< FUSE HOLDER >
0 FH900 1-533-223-51 FUSE HOLDER
0 FH901 1-533-223-51 FUSE HOLDER
< FUSIBLE RESISTOR >
0 FR910 1-246-373-11 FUSIBLE 1 10% 1/2W F
< IC >
0 IC910 6-713-934-01 IC STR-A6159M
0 IC920 6-706-347-01 IC STR-W6735N (US, CND, TW)
0 IC920 6-706-348-01 IC STR-W6765N (Except US, CND, TW)
IC940 6-711-947-01 IC MM1431CURE
IC950 6-711-947-01 IC MM1431CURE
< LINE FILTER >
0 LF001 1-460-618-11 COIL, LINE FILTER (US, CND, TW)
0 LF001 1-697-363-11 LINE FILTER COIL (Except US, CND, TW)
< PHOTO COUPLER >
0 PC901 6-600-877-01 PHOTO COUPLER EL816M (B) (DTE-S)
0 PC902 6-600-877-01 PHOTO COUPLER EL816M (B) (DTE-S)
0 PC903 6-600-877-01 PHOTO COUPLER EL816M (B) (DTE-S)
< TRANSISTOR >
0 Q901 6-550-296-01 TRANSISTOR 2SA1980-AT
0 Q920 8-729-802-94 TRANSISTOR 2SD1388TP-4
0 Q921 6-552-949-01 TRANSISTOR LTC044EUBFS8TL
0 Q922 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
0 Q923 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q960 6-552-949-01 TRANSISTOR LTC044EUBFS8TL
Q961 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
Q962 6-552-949-01 TRANSISTOR LTC044EUBFS8TL
< RESISTOR >
0 R900 1-219-759-51 METAL 1M 5% 1/2W F
0 R901 1-216-797-91 METAL CHIP 10 5% 1/10W
0 R902 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R903 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R904 1-216-833-91 METAL CHIP 10K 5% 1/10W
0 R905 1-216-845-91 METAL CHIP 100K 5% 1/10W
0 R910 1-216-839-91 METAL CHIP 33K 5% 1/10W
0 R911 1-249-390-91 CARBON 5.6 5% 1/4W F
0 R913 1-215-904-51 METAL OXIDE 100K 5% 2W F
0 R914 1-216-789-91 METAL CHIP 2.2 5% 1/10W
0 R915 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R916 1-216-855-91 METAL CHIP 680K 5% 1/10W
0 R920 1-216-809-91 METAL CHIP 100 5% 1/10W
0 R921 1-216-361-61 METAL OXIDE 0.22 5% 2W F
(US, CND, TW)
0 R921 1-245-277-61 METAL OXIDE 0.36 5% 2W F
(Except US, CND, TW)
0 R922 1-216-363-61 METAL OXIDE 0.33 5% 2W F
(US, CND, TW)
0 R922 1-216-365-61 METAL OXIDE 0.47 5% 2W F
(Except US, CND, TW)
0 R923 1-215-929-51 METAL OXIDE 100K 5% 3W F
(US, CND, TW)
0 R923 1-216-492-51 METAL OXIDE 82K 5% 3W F
(Except US, CND, TW)
0 R924 1-249-401-91 CARBON 47 5% 1/4W F
0 R925 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R926 1-249-416-91 CARBON 820 5% 1/4W F
0 R927 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R928 1-216-864-91 SHORT CHIP 0 (US, CND, TW)
0 R929 1-216-821-91 METAL CHIP 1K 5% 1/10W
0 R930 1-216-821-91 METAL CHIP 1K 5% 1/10W
0 R931 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R932 1-216-843-91 METAL CHIP 68K 5% 1/10W
R940 1-216-821-11 METAL CHIP 1K 5% 1/10W
R941 1-216-821-11 METAL CHIP 1K 5% 1/10W
R942 1-216-853-11 METAL CHIP 470K 5% 1/10W
R943 1-216-821-11 METAL CHIP 1K 5% 1/10W
R944 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R945 1-216-809-11 MET
AL CHIP 100 5% 1/10W
R946 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R947 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R949 1-216-821-11 METAL CHIP 1K 5% 1/10W
R950 1-216-821-11 METAL CHIP 1K 5% 1/10W
R951 1-216-817-11 METAL CHIP 470 5% 1/10W
R953 1-216-833-11 METAL CHIP 10K 5% 1/10W
R955 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R956 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R957 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R959 1-216-833-11 METAL CHIP 10K 5% 1/10W
R960 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R961 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R962 1-216-837-11 METAL CHIP 22K 5% 1/10W
R963 1-216-809-11 METAL CHIP 100 5% 1/10W
< TRANSFORMER >
0 T901 1-445-781-11 CONVERTER TRANSFORMER
0 T902 1-443-996-11 TRANSFORMER, CONVERTER
(Except US, CND, TW)
0 T902 1-443-997-11 TRANSFORMER, CONVERTER (US, CND, TW)
< THERMISTOR >
0 TH900 1-802-947-31 THERMISTOR, POWER
0 TH920 1-811-028-11 THERMISTOR, POSITIVE
< VARISTOR >
0 VDR900 1-811-165-31 VARISTOR (TVR10471-D)
*************************************************************
SUB KEY BOARD
*************
< CAPACITOR >
C001 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C002 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN002 1-580-056-21 PIN, CONNECTOR (SMD) 3P
< SWITCH >
S001 1-786-653-11 SWITCH, TACTILE (
?
/1)
S002 1-786-653-11 SWITCH, TACTILE (LINK)
*************************************************************
POWER SUB KEY
Ver. 1.1
