Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WCT770
34
SUB LED BOARD
*************
< CONNECTOR >
CN901 1-580-056-21 PIN, CONNECTOR (SMD) 3P
< LED >
D901 6-502-843-01 LED CL-165HR/HG5-D-T (ON/STANDBY LAMP)
< RESISTOR >
R900 1-216-813-11 METAL CHIP 220 5% 1/10W
R901 1-216-808-11 METAL CHIP 82 5% 1/10W
R904 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1979-519-A SUB MAIN BOARD, COMPLETE (See Note)
************************
< CAPACITOR >
C05 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C101 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C102 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C106 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C107 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C109 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C114 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C115 1-117-681-11 ELECT CHIP 100uF 20% 16V
C116 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C118 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-137-765-21 ELECT CHIP 47uF 20% 16V
C120 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C122 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C125 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C129 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C130 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C131 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C132 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C134 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C135 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C136 1-116-730-11 CERAMIC CHIP 2.2uF 10% 10V
C137 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C140 1-118-048-11 CERAMIC CHIP 2.2uF 10% 50V
C141 1-117-681-11 ELECT CHIP 100uF 20% 16V
C148 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C152 1-118-048-11 CERAMIC CHIP 2.2uF 10% 50V
* C155 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
C157 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C158 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C161 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C162 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C165 1-118-048-11 CERAMIC CHIP 2.2uF 10% 50V
C166 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
* C167 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
C170 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C172 1-118-048-11 CERAMIC CHIP 2.2uF 10% 50V
C174 1-118-048-11 CERAMIC CHIP 2.2uF 10% 50V
C175 1-117-681-11 ELECT CHIP 100uF 20% 16V
C177 1-118-048-11 CERAMIC CHIP 2.2uF 10% 50V
C178 1-117-681-11 ELECT CHIP 100uF 20% 16V
C179 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C184 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C185 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C186 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C187 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C188 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C189 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C191 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C194 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C195 1-112-806-11 ELECT CHIP 47uF 20% 50V
C196 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C197 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C198 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C199 1-117-681-11 ELECT CHIP 100uF 20% 16V
C201 1-165-492-21 ELECT CHIP 100uF 20% 10V
C203 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C204 1-118-692-11 ELECT CHIP 470uF 20% 35V
C205 1-118-692-11 ELECT CHIP 470uF 20% 35V
C206 1-118-692-11 ELECT CHIP 470uF 20% 35V
C207 1-118-692-11 ELECT CHIP 470uF 20% 35V
C209 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C210 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C211 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN102 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN107 1-815-763-71 CONNECTOR, FFC/FPC 24P
CN109 1-842-566-12 HEADER ASSEMBLY FOR PWB 4P
CN111 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
CN113 1-691-550-11 PIN, CONNECTOR (1.5 mm) (SMD) 3P
CN114 1-779-992-11 PIN, CONNECTOR (PWB) 8P
< DIODE >
D101 6-502-961-01 DIODE DA2J10100L
D111 6-503-775-01 DIODE CRH02 (T5R, SONY, XM)
D112 6-502-966-01 DIODE DZ2J056M0L
< LUG TERMINAL >
* ET100 1-780-408-11 TERMINAL, LUG
< COIL >
FB100 1-469-647-21 FERRITE, EMI (SMD) (1608)
FB101 1-412-977-41 INDUCTOR 0.68uH
FB102 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB103 1-400-697-31 BEAD, FERRITE (CHIP) (1608)
FB104 1-400-697-31 BEAD, FERRITE (CHIP) (1608)
FB105 1-400-697-31 BEAD, FERRITE (CHIP) (1608)
< IC >
IC100 A-2041-181-A IC R5F212BASNFP (for SERVICE)
Note: When the complete SUB MAIN board is replaced, refer to “NOTE OF REPLACING THE IC104
ON THE SUB MAIN BOARD AND THE COMPLETE SUB MAIN BOARD” on page 4.
