Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SCD-XE800
4545
R1783 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1801 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R1900 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1901 1-216-813-11 METAL CHIP 220 5% 1/10W
R1902 1-216-864-11 SHORT CHIP 0
R1903 1-216-809-11 METAL CHIP 100 5% 1/10W
R1904 1-216-809-11 METAL CHIP 100 5% 1/10W
R2101 1-218-841-11 METAL CHIP 560 0.5% 1/10W
R2110 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R2114 1-216-801-11 METAL CHIP 22 5% 1/10W
R2115 1-216-864-11 SHORT CHIP 0
R2119 1-216-864-11 SHORT CHIP 0
R2129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2133 1-216-864-11 SHORT CHIP 0
R2134 1-216-864-11 SHORT CHIP 0
R2150 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2151 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2152 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2155 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2156 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2157 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2158 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2159 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2160 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2176 1-216-864-11 SHORT CHIP 0
R2177 1-216-864-11 SHORT CHIP 0
R2178 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2180 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2184 1-216-809-11 METAL CHIP 100 5% 1/10W
R2185 1-216-809-11 METAL CHIP 100 5% 1/10W
R2187 1-216-805-11 METAL CHIP 47 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB201 1-233-413-11 RES, CHIP NETWORK 2.2K (3216)
RB1103 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1104 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1105 1-234-944-21 RES, NETWORK 47 (1005X4)
RB1106 1-234-944-21 RES, NETWORK 47 (1005X4)
RB1107 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1108 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1109 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1110 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1111 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1112 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1113 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1114 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1115 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
< VIBRATOR >
X501 1-795-121-21 VIBRATOR, CERAMIC (5MHz)
X1900 1-813-218-21 VIBRATOR, CRYSTAL (27MHz)
************************************************************
MOTOR BOARD
************
< CONNECTOR >
CN010 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN011 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
SW010 1-572-086-11 SWITCH, LEAF (CHUCKING)
************************************************************
OUT-SW BOARD
*************
< SWITCH >
SW011 1-762-424-11 SWITCH, MICRO (TRAY OPEN/CLOSE)
************************************************************
POWER BOARD
*************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C50 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C51 1-126-961-11 ELECT 2.2uF 20% 50V
0
C52 1-112-887-51 CERAMIC 0.01uF 20% 250V
C53 1-126-943-11 ELECT 2200uF 20% 25V
C54 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C55 1-130-479-91 MYLAR 0.0047uF 5% 50V
C56 1-136-162-00 FILM 0.056uF 5% 50V
C57 1-126-941-11 ELECT 470uF 20% 25V
C58 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C60 1-126-941-11 ELECT 470uF 20% 25V
C101 1-128-576-11 ELECT 100uF 20% 63V
C102 1-128-548-11 ELECT 4700uF 20% 25V
C103 1-126-946-11 ELECT 6800uF 20% 25V
C104 1-126-939-11 ELECT 10000uF 20% 16V
C110 1-126-964-11 ELECT 10uF 20% 50V
C111 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C112 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C113 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C114 1-126-767-11 ELECT 1000uF 20% 16V
C115 1-126-936-11 ELECT 3300uF 20% 16V
C116 1-126-918-51 ELECT 4700uF 20% 6.3V
C121 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C125 1-126-965-91 ELECT 22uF 20% 50V
C126 1-104-662-91 ELECT 22uF 20% 25V
< CONNECTOR >
*
CN003 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
CN103 1-784-922-11 PIN, CONNECTOR 5P
CN104 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
CN105 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN106 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
< DIODE >
0
D52 8-719-053-18 DIODE 1SR154-400TE-25
0
D53 8-719-053-18 DIODE 1SR154-400TE-25
0
D54 8-719-053-18 DIODE 1SR154-400TE-25
0
D55 8-719-053-18 DIODE 1SR154-400TE-25
0
D56 6-502-961-01 DIODE DA2J10100L
0
D57 6-502-961-01 DIODE DA2J10100L
0
D58 6-502-961-01 DIODE DA2J10100L
0
D102 8-719-053-18 DIODE 1SR154-400TE-25
0
D104 8-719-053-18 DIODE 1SR154-400TE-25
0
D105 8-719-053-18 DIODE 1SR154-400TE-25
0
D106 8-719-053-18 DIODE 1SR154-400TE-25
MAIN MOTOR OUT-SW POWER
