Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SCD-XE800
46
0 D107 8-719-053-18 DIODE 1SR154-400TE-25
0 D108 8-719-053-18 DIODE 1SR154-400TE-25
0 D109 8-719-053-18 DIODE 1SR154-400TE-25
0 D110 8-719-053-18 DIODE 1SR154-400TE-25
0 D111 8-719-053-18 DIODE 1SR154-400TE-25
0 D112 8-719-053-18 DIODE 1SR154-400TE-25
0 D113 8-719-053-18 DIODE 1SR154-400TE-25
0 D114 8-719-053-18 DIODE 1SR154-400TE-25
0 D115 8-719-053-18 DIODE 1SR154-400TE-25
0 D116 8-719-053-18 DIODE 1SR154-400TE-25
0 D129 8-719-083-70 DIODE UDZSUSTE-1727B
0 D130 6-503-015-01 DIODE DZ2J051M0L
< EARTH TERMINAL >
* EE51 1-537-738-21 TERMINAL, EARTH
* EE102 1-537-738-21 TERMINAL, EARTH
< FUSE HOLDER >
FH01 1-533-233-11 FUSE HOLDER
FH02 1-533-233-11 FUSE HOLDER
< IC >
0 IC51 8-759-450-47 IC BA05T
0 IC52 6-708-659-01 IC BA00BC0WT-V5
0
IC101 8-759-473-41 IC BA10T
0 IC102 8-759-473-41 IC BA10T
0 IC103 6-708-659-01 IC BA00BC0WT-V5
< TRANSISTOR >
0 Q51 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
0 Q52 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
0 Q101 6-550-744-01 TRANSISTOR 2SA1900T100Q
< RESISTOR >
R51 1-216-833-11 METAL CHIP 10K 5% 1/10W
R52 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R53 1-216-837-11 METAL CHIP 22K 5% 1/10W
R54 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R55 1-216-833-11 METAL CHIP 10K 5% 1/10W
R56 1-216-847-11 METAL CHIP 150K 5% 1/10W
R57 1-216-843-11 METAL CHIP 68K 5% 1/10W
0 R60 1-249-389-91 CARBON 4.7 5% 1/4W F
R61 1-216-819-11 METAL CHIP 680 5% 1/10W
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R103 1-249-423-91 CARBON 3.3K 5% 1/4W F
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R106 1-216-837-11 METAL CHIP 22K 5% 1/10W
R107 1-216-847-11 METAL CHIP 150K 5% 1/10W
R108 1-216-843-11 METAL CHIP 68K 5% 1/10W
R109 1-216-836-11 METAL CHIP 18K 5% 1/10W
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
< RELAY >
0 RY01 1-755-266-11 RELAY, AC POWER
< TRANSFORMER >
0 T002 1-443-517-11 POWER TRANSFORMER
< THERMISTOR >
0 TH50 1-804-046-21 THERMISTOR, POSITIVE (RXE030)
************************************************************
TRANS BOARD
************
< CONNECTOR >
* CN001 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
*************************************************************
MISCELLANEOUS
**************
6 1-828-338-11 WIRE (FLAT TYPE) (15 CORE)
0 54 1-834-966-41 POWER-SUPPLY CORD (AEP)
0 54 1-837-309-21 CORD, POWER-SUPPLY (UK)
0 152 8-820-322-04 OPTICAL PICK-UP BLOCK (KHM-313CAB/C2RP)
155 1-838-107-51 WIRE, FLAT TYPE (24 CORE)
0 F001 1-532-499-33 FUSE (T400mAL/250V)
M001 A-4604-363-A MOTOR (L) ASSY (LOADING)
0 T001 1-445-874-11 POWER TRANSFORMER
*************************************************************
ACCESSORIES
************
1-489-030-11 REMOTE COMMANDER (RM-ASU097)
1-790-735-12 CORD, CONNECTION
(Audio connecting cord (Red and White plugs))
4-193-086-11 MANUAL, INSTRUCTION (ENGLISH) (UK)
4-193-086-21 MANUAL, INSTRUCTION
(FRENCH, SPANISH, GERMAN, DUTCH,
ITALIAN, SWEDISH, POLISH) (AEP)
4-193-086-31 MANUAL, INSTRUCTION (DANISH, FINNISH)
(AEP)
4-193-086-41 MANUAL, INSTRUCTION (PORTUGUESE) (AEP)
POWER TRANS
