PRIMARY MODE
MODE AT PRODUCTION MODE 8 MODE 9 MODE 10 MODE 11 MODE 12 MODE 13 MODE 14 MODE 15
RESOLUTION 800 X 600 800 X 600 800 X 600 800 X 600 — — 832 X 624 1024 X 768
CLOCK 36.000 MHz 40.000 MHz 49.500 MHz 56.250 MHz — — 57.285 MHz 65.000 MHz
— HORIZONTAL —
H-FREQ 35.156 kHz 37.879 kHz 46.875 kHz 53.674 kHz — — 46.727 kHz 48.363 kHz
usec usec usec usec — — usec usec
H. TOTAL 28.444 26.400 21.333 18.631 — — 20.110 20.677
H. BLK 6.222 6.400 5.172 4.409 — — 5.586 4.923
H. FP 0.667 1.000 0.323 0.569 — — 0.559 0.369
H. SYNC 0.889 3.200 1.616 1.138 — — 1.117 2.092
H. BP 4.667 2.200 3.232 2.702 — — 3.910 2.462
H. ACTIV 22.222 20.000 16.162 14.222 — — 14.524 15.754
— VERTICAL —
V. FREQ(Hz) 56.250 Hz 60.317 Hz 75.000 Hz 85.061 Hz — — 74.553 Hz 60.004 Hz
lines lines lines lines — — lines lines
V. TOTAL 625 628 625 631 — — 667 806
V. BLK 25 28 25 31 — — 43 38
V. FP 1 1 1 1 — — 3 3
V. SYNC 2 4 3 3 — — 3 6
V. BP 22 23 21 27 — — 37 29
V. ACTIV 600 600 600 600 — — 624 768
— SYNC —
INT(G) NO NO NO NO — — NO NO
EXT(H/V)/POLARITY YES N/N YES P/P NO P/P YES P/P — — YES N/N YES N/N
EXT(CS)/POLARITY NO NO NO NO — — NO NO
INT/NON INT NON INT NON INT NON INT NON INT — — NON INT NON INT
PRIMARY MODE
MODE AT PRODUCTION MODE 16 MODE 17 MODE 18 MODE 19 MODE 20 MODE 21 MODE 22 MODE 23
RESOLUTION 1024 X 768 1024 X 768 — 1024 X 768 800 X 600 1024 X 768 1024 X 768 848 X 480
CLOCK 75.000 MHz 78.750 MHz — 80.000 MHz 50.000 MHz 71.640 MHz 80.000 MHz 38.336 MHz
— HORIZONTAL —
H-FREQ 56.476 kHz 60.023 kHz — 60.241 kHz 48.077 kHz 53.946 kHz 60.241 kHz 35.300 kHz
usec usec — usec usec usec usec usec
H. TOTAL 17.707 16.660 — 16.600 20.800 18.537 16.600 28.328
H. BLK 4.053 3.657 — 3.800 4.800 4.243 3.800 6.208
H. FP 0.320 0.203 — 0.400 1.120 0.223 0.400 1.409
H. SYNC 1.813 1.219 — 1.200 2.400 2.457 2.200 3.130
H. BP 1.920 2.235 — 2.200 1.280 1.563 1.200 1.669
H. ACTIV 13.653 13.003 — 12.800 16.000 14.294 12.800 22.120
— VERTICAL —
V. FREQ(Hz) 70.069 Hz 75.029 Hz — 74.927 Hz 72.188 Hz 66.110 Hz 74.927 Hz 59.932 Hz
lines lines — lines lines lines lines lines
V. TOTAL 806 800 — 804 666 816 804 589
V. BLK 38 32 — 36 66 48 36 109
V. FP 3 1 — 3 37 8 3 11
V. SYNC 6 3 — 3 6 4 3 3
V. BP 29 28 — 30 23 36 30 95
V. ACTIV 768 768 — 768 600 768 768 480
— SYNC —
INT(G) NO NO — NO NO NO NO NO
EXT(H/V)/POLARITY YES N/N YES P/P — YES N/N YES N/N YES N/N YES N/N YES N/N
EXT(CS)/POLARITY NO NO — NO NO NO NO NO
INT/NON INT NON INT NON INT — NON INT NON INT NON INT NON INT NON INT
