PRIMARY MODE
MODE AT PRODUCTION MODE 24 MODE 25 MODE 26 MODE 27 MODE 28 MODE 29 MODE 30 MODE 31
RESOLUTION 640 X 400 640 X 350 640 X 400 640 X 480 1024 X 768 640 X 400 720 X 400 800 X 600
CLOCK 25.180 MHz 31.500 MHz 31.500 MHz 31.500 MHz 65.000 MHz 24.870 MHz 28.320 MHz 36.000 MHz
— HORIZONTAL —
H-FREQ 31.475 kHz 37.861 kHz 37.861 kHz 37.861 kHz 48.077 kHz 30.478 kHz 31.467 kHz 35.156 kHz
usec usec usec usec usec usec usec usec
H. TOTAL 31.771 26.413 26.413 26.413 20.800 32.811 31.780 28.444
H. BLK 6.354 6.095 6.095 6.095 5.046 7.077 6.356 6.222
H. FP 0.953 1.016 1.016 0.762 0.462 0.322 0.636 0.167
H. SYNC 2.542 2.032 2.032 1.270 1.477 3.860 3.814 5.111
H. BP 2.859 3.048 3.048 4.063 3.108 2.895 1.907 0.944
H. ACTIV 25.417 20.317 20.317 20.317 15.754 25.734 25.424 22.222
— VERTICAL —
V. FREQ(Hz) 70.100 Hz 85.080 Hz 85.080 Hz 72.809 Hz 59.797 Hz 59.996 Hz 50.026 Hz 56.160 Hz
lines lines lines lines lines lines lines lines
V. TOTAL 449 445 445 520 804 508 629 626
V. BLK 49 95 45 40 36 108 229 26
V. FP 11 32 1 9 3 37 102 2
V. SYNC 2 3 3 3 4 2 2 1
V. BP 36 60 41 28 29 69 125 23
V. ACTIV 400 350 400 480 768 400 400 600
— SYNC —
INT(G) NO NO NO NO NO NO NO NO
EXT(H/V)/POLARITY YES N/N YES P/N YES N/P YES N/N YES N/N YES N/N YES N/N YES N/N
EXT(CS)/POLARITY NO NO NO NO NO NO NO NO
INT/NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT
PRIMARY MODE
MODE AT PRODUCTION MODE 32 MODE 33 MODE 34 MODE 35 MODE 36
RESOLUTION 800 X 600 1024 X 768 1024 X 768 1024 X 768 800 X 600
CLOCK 50.000 MHz 64.000 MHz 65.000 MHz 64.000 MHz 39.530 MHz
— HORIZONTAL —
H-FREQ 48.828 kHz 48.780 kHz 48.363 kHz 48.485 kHz 37.434 kHz
usec usec usec usec usec
H. TOTAL 20.480 20.500 20.677 20.625 26.714
H. BLK 4.480 4.500 4.923 4.625 6.476
H. FP 0.960 1.000 0.615 1.219 1.012
H. SYNC 1.600 1.500 3.200 1.219 2.530
H. BP 1.920 2.000 1.108 2.188 2.934
H. ACTIV 16.000 16.000 15.754 16.000 20.238
— VERTICAL —
V. FREQ(Hz) 66.888 Hz 59.561 Hz 60.078 Hz 59.637 Hz 59.608 Hz
lines lines lines lines lines
V. TOTAL 730 819 805 813 628
V. BLK 130 51 37 45 28
V. FP 48 12 3 39 5
V. SYNC 6 6 3 3 1
V. BP 76 33 31 3 22
V. ACTIV 600 768 768 768 600
— SYNC —
INT(G) YES NO NO NO NO
EXT(H/V)/POLARITY YES N/N YES N/N YES N/N YES N/N YES N/N
EXT(CS)/POLARITY NO NO NO NO NO
INT/NON INT NON INT NON INT NON INT NON INT NON INT
