24
Identifying parts
DT 18-55mm F3.5-5.6 SAM
(Supplied with the SLT-A77K/A77VK)
DT 16-50mm F2.8 SSM
(Supplied with the SLT-A77Q/A77VQ)
DT 18-135mm F3.5-5.6 SAM
(Supplied with the SLT-A77M/A77VM)
A
Focusing ring
B Zoom ring
C Zoom lock switch
D Focal-length index
E Lens contacts
F Lens hood index
G Distance scale
H Distance index
I Focal-length scale
J Focusing mode switch
K Mounting index
• The DT 18-55mm F3.5-5.6
SAM/DT 16-50mm F2.8 SSM/
DT 18-135mm F3.5-5.6 SAM are
designed for Sony A-mount
cameras (models equipped with
an APS-C sized image sensor).
You cannot use these lenses on
35mm-format cameras.
• For the lenses other than DT 18-
55mm F3.5-5.6 SAM/DT 16-
50mm F2.8 SSM/DT 18-135mm
F3.5-5.6 SAM, refer to the
operating instructions supplied
with the lens.
Lens
