Sony SLV-ED60PS - Page 34

4-11
• Waveforms
2 IC201 *¡ REC/PB
3 IC201 @¡ REC/PB
4 IC201 @§ REC/PB
5 IC201 #º REC
1.4 Vp-p (2V)
5.2 Vp-p (2 V)
REC: 360 mVp-p (H)
PB : 456 mVp-p (H)
REC: 528 mVp-p (H)
PB : 624 mVp-p (H)
1.1 Vp-p (H)
6 IC201 %º REC/PB
7 IC201 %• REC/PB
8 IC201 ^º REC/PB
9 IC201 &¡ REC/PB
0 IC201 &∞ REC/PB
5.4 Vp-p (H)
REC: 512 mVp-p (H)
PB : 608 mVp-p (H)
REC: 352 mVp-p (H)
PB : 552 mVp-p (H)
120 mVp-p (3.579545 MHz)
552 mVp-p (4.433619 MHz)
1 IC201 *• REC
