4-12
5.3 Vp-p (2V)
6 IC161 #• REC/PB
7 IC161 #ª REC/PB
8 IC161 $º REC/PB
9 IC161 $£ REC/PB
0 IC161 $∞ REC/PB
!¡ IC161 %£ REC/PB
4.4 Vp-p (2 V)
4.7 Vp-p (2 V)
4.9 Vp-p (2 V)
1.8 Vp-p (H)
3.4 Vp-p (17.734475 MHz)
1.8 Vp-p (H)
1 IC161 @¢ REC/PB
2 IC161 &º REC/PB
3 IC161 &£ REC/PB
4 IC161 #¡ REC
5 IC161 #™ REC
2.1 Vp-p (32.768 kHz)
3.5 Vp-p (10 MHz)
5.6 Vp-p (2 V)
5.6 Vp-p (2 V)
• Waveforms
