7-16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-216-089-91 RES,CHIP 47K 5% 1/10W
(10,30,40:EXCEPT EE)
R603 1-216-452-11 METAL OXIDE 180 5% 2W F
R604 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R605 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R606 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(10,30,40:EXCEPT EE)
R607 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R608 1-249-414-11 CARBON 560 5% 1/4W F
R609 1-247-815-91 CARBON 220 5% 1/4W
R610 1-247-815-91 CARBON 220 5% 1/4W
R611 1-216-049-91 RES,CHIP 1K 5% 1/10W
(B,CP,VC,VC1,VC2)
R612 1-216-089-91 RES,CHIP 47K 5% 1/10W
R613 1-215-907-11 METAL OXIDE 22 5% 3W F
R614 1-215-857-11 METAL OXIDE 10 5% 1W F
R615 1-216-049-91 RES,CHIP 1K 5% 1/10W
(B,CP,VC,VC1,VC2)
R616 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R617 1-216-049-91 RES,CHIP 1K 5% 1/10W
(B,CP,VC,VC1,VC2)
R618 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
(B,CP,VC,VC1,VC2)
R622 1-260-073-11 CARBON 5.6 5% 1/2W
R623 1-260-073-11 CARBON 5.6 5% 1/2W
R660 1-216-049-91 RES,CHIP 1K 5% 1/10W
R661 1-216-121-91 RES,CHIP 1M 5% 1/10W
R662 1-216-041-00 METAL CHIP 470 5% 1/10W
R663 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R666 1-216-295-91 SHORT 0
R667 1-216-037-00 METAL CHIP 330 5% 1/10W
R668 1-216-025-91 RES,CHIP 100 5% 1/10W
R669 1-216-025-91 RES,CHIP 100 5% 1/10W
R670 1-216-041-00 METAL CHIP 470 5% 1/10W
R671 1-216-295-91 SHORT 0
R672 1-216-049-91 RES,CHIP 1K 5% 1/10W
(B,EE,EG)
R702 1-216-295-91 SHORT 0
R704 1-216-041-00 METAL CHIP 470 5% 1/10W
R705 1-216-041-00 METAL CHIP 470 5% 1/10W
!R711 1-212-895-00 FUSIBLE 390 5% 1/4W F
R713 1-216-025-91 RES,CHIP 100 5% 1/10W
R714 1-216-113-00 METAL CHIP 470K 5% 1/10W
R731 1-216-041-00 METAL CHIP 470 5% 1/10W
(EXCEPT UX,EE,EG)
R733 1-216-041-00 METAL CHIP 470 5% 1/10W
(EXCEPT UX)
R751 1-216-009-91 RES,CHIP 22 5% 1/10W
(10:EE/30:EE/40:EE)
R754 1-216-041-00 METAL CHIP 470 5% 1/10W
R755 1-216-041-00 METAL CHIP 470 5% 1/10W
R756 1-216-073-00 METAL CHIP 10K 5% 1/10W
(10,30,40:EXCEPT EE)
R757 1-216-049-91 RES,CHIP 1K 5% 1/10W
(10,30,40:EXCEPT EE)
R800 1-216-101-00 METAL CHIP 150K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R801 1-216-073-00 METAL CHIP 10K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R802 1-216-073-00 METAL CHIP 10K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R803 1-216-081-00 METAL CHIP 22K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R804 1-216-073-00 METAL CHIP 10K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R805 1-216-073-00 METAL CHIP 10K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R806 1-216-073-00 METAL CHIP 10K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R807 1-216-085-00 METAL CHIP 33K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R813 1-216-073-00 METAL CHIP 10K 5% 1/10W
(10/30:EE/EXCEPT 40:EE/X10/X40)
R850 1-216-025-91 RES,CHIP 100 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R851 1-216-077-00 METAL CHIP 15K 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R852 1-216-081-00 METAL CHIP 22K 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R853 1-216-049-91 RES,CHIP 1K 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R856 1-216-097-91 RES,CHIP 100K 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R857 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R858 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R859 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R860 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R861 1-216-117-00 METAL CHIP 680K 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R862 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(EXCEPT CP,EE,10,X10,X40)
R870 1-216-097-91 RES,CHIP 100K 5% 1/10W
(30:EE)
R871 1-216-073-00 METAL CHIP 10K 5% 1/10W
(30:EE)
R872 1-216-073-00 METAL CHIP 10K 5% 1/10W
(30:EE)
R873 1-216-049-91 RES,CHIP 1K 5% 1/10W
(30:EE)
R874 1-216-033-00 METAL CHIP 220 5% 1/10W
(30:EE)
R875 1-216-077-00 METAL CHIP 15K 5% 1/10W
(30:EE)
R876 1-216-073-00 METAL CHIP 10K 5% 1/10W
(30:EE)
R877 1-216-077-00 METAL CHIP 15K 5% 1/10W
(30:EE)
R878 1-216-089-91 RES,CHIP 47K 5% 1/10W
(30:EE)
R879 1-216-073-00 METAL CHIP 10K 5% 1/10W
(30:EE)
R880 1-216-081-00 METAL CHIP 22K 5% 1/10W
(30:EE)
MA-338
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
