7-17
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R881 1-216-081-00 METAL CHIP 22K 5% 1/10W
(30:EE)
R882 1-216-081-00 METAL CHIP 22K 5% 1/10W
(30:EE)
R883 1-216-089-91 RES,CHIP 47K 5% 1/10W
(30:EE)
R884 1-216-089-91 RES,CHIP 47K 5% 1/10W
(30:EE)
R885 1-216-073-00 METAL CHIP 10K 5% 1/10W
(30:EE)
R886 1-216-033-00 METAL CHIP 220 5% 1/10W
(30:EE)
R887 1-216-081-00 METAL CHIP 22K 5% 1/10W
(30:EE)
R888 1-216-097-91 RES,CHIP 100K 5% 1/10W
(30:EE)
R968 1-216-101-00 METAL CHIP 150K 5% 1/10W
(25:B/40:B)
R969 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(25:B/40:B)
R970 1-216-085-00 METAL CHIP 33K 5% 1/10W
(25:B/40:B)
R971 1-216-085-00 METAL CHIP 33K 5% 1/10W
(25:B/40:B)
R972 1-216-083-00 METAL CHIP 27K 5% 1/10W
(25:B/40:B)
R973 1-216-105-91 RES,CHIP 220K 5% 1/10W
(25:B/40:B)
R974 1-216-081-00 METAL CHIP 22K 5% 1/10W
(25:B/40:B)
R975 1-216-295-91 SHORT 0 (25:B/40:B)
R976 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
(25:B/40:B)
R977 1-216-089-91 RES,CHIP 47K 5% 1/10W
(25:B/40:B)
R978 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
(25:B/40:B)
R979 1-216-073-00 METAL CHIP 10K 5% 1/10W
(25:B/40:B)
R980 1-216-097-91 RES,CHIP 100K 5% 1/10W
(25:B/40:B)
R981 1-216-083-00 METAL CHIP 27K 5% 1/10W
(25:B/40:B)
R982 1-216-089-91 RES,CHIP 47K 5% 1/10W
(25:B/40:B)
R983 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
(25:B/40:B)
R985 1-216-041-00 METAL CHIP 470 5% 1/10W
(25:B/40:B)
R986 1-216-089-91 RES,CHIP 47K 5% 1/10W
(25:B/40:B)
R988 1-216-073-00 METAL CHIP 10K 5% 1/10W
(25:B/40:B)
R989 1-216-049-91 RES,CHIP 1K 5% 1/10W
(25:B/40:B)
R990 1-216-295-91 SHORT 0 (25:B/40:B)
R993 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
(25:B/40:B)
R994 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
(25:B/40:B)
R995 1-216-073-00 METAL CHIP 10K 5% 1/10W
(25:B/40:B)
R996 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
(25:B/40:B)
R997 1-216-073-00 METAL CHIP 10K 5% 1/10W
(25:B/40:B)
R998 1-216-073-00 METAL CHIP 10K 5% 1/10W
(25:B/40:B)
R999 1-216-295-91 SHORT 0 (25:B/40:B)
< SWITCH >
S100 1-771-155-11 SWITCH, ROTARY (MECHANISM MODE)
S101 1-762-108-11 SWITCH, PUSH (1 KEY) (REC PROOF)
S160 1-571-588-11 SWITCH, SLIDE (ON PAL TV/NTSC 4.43)
(EXCEPT 10:AE1,AE2)
S460 1-771-574-21 SWITCH, TACTILE (POWER)
S461 1-771-574-21 SWITCH, TACTILE (EJECT)
S462 1-771-574-21 SWITCH, TACTILE (PAUSE)
S463 1-771-574-21 SWITCH, TACTILE (REC)
S464 1-771-574-21 SWITCH, TACTILE (PROGRAM–)
S465 1-771-574-21 SWITCH, TACTILE(AUTO SET UP/RF CHANNEL)
S466 1-771-574-21 SWITCH, TACTILE(PROGRAM+)
< TRANSFORMER >
T320 1-431-097-11 TRANSFORMER, BIAS OSCILLATION
< TUNER >
TU700 1-693-433-11 TUNER, IF (BTF-3MC404)
(EXCEPT UX,B,VP1,VP2,EE,EG)
TU700 1-693-435-11 TUNER, IF (BTF-3MC445) (25:B/40:B)
TU700 1-693-431-11 TUNER, IF (BTF-2MC421)
(10:AE1,AE2/20:VP1,VP2/25:CP,VC/X25)
TU701 1-693-434-11 TUNER, IF (BTF-3MU604) (20:UX/30:UX/45:UX)
TU701 1-693-431-11 TUNER, IF (BTF-2MC421)
(10:EE,EG/30:EE/40:EE,EG,X10,X40)
< VIBRATOR >
X160 1-579-463-11 VIBRATOR, CRYSTAL 32.768KHz
X161 1-577-289-11 VIBRATOR, CRYSTAL 17.734475KHz
X200 1-579-608-11 VIBRATOR, CRYSTAL 4.43MHz
! 1-468-271-31 POWER BLOCK ETXNY165E1D
************************
(Ref.No.:9,000 Series)
< CAPACITOR >
C102 1-216-964-11 ELECT 10uF 50V
C107 1-216-965-11 ELECT 22uF 50V
C201 1-216-968-11 ELECT 100uF 50V
C301 9-880-907-01 ELECT 820uF 25V
C302 1-216-968-11 ELECT 100uF 50V
MA-338
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
