7-18
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C401 9-880-908-01 ELECT 820uF 16V
C402 1-126-925-11 ELECT 470uF 10V
C501 1-126-960-11 ELECT 1uF 50V
C601 9-880-909-01 ELECT 330uF 25V
< DIODE >
D001 8-719-066-97 DIODE 1N4007
D002 8-719-066-97 DIODE 1N4007
D003 8-719-066-97 DIODE 1N4007
D004 8-719-066-97 DIODE 1N4007
D101 9-880-910-01 DIODE 1SS130T-77
D102 9-880-911-01 DIODE FE1E
D103 9-880-912-01 DIODE BYV36E
D104 9-880-913-01 DIODE 1SS130T-77
D201 9-880-914-01 DIODE FE1E
D301 9-880-915-01 DIODE FE3C
D401 9-880-916-01 DIODE SB260
D601 9-880-917-01 DIODE FE1E
< IC >
IC101 9-880-919-01 IC UC3844A
IC501 9-880-920-01 IC KA431AZTA
< PHOTOCOUPLER >
!PC101 9-880-921-01 PHOTOCOUPLER LTV817BM-V
< TRANSISTOR >
Q101 9-880-922-01 POWER FET SSS2N90-A
Q102 8-729-423-29 TRANSISTOR 2SC3311A-QTA
< VARISTOR >
!Z001 9-880-923-01 METALOXID-VARISTOR S10K460
< ZENER DIODE >
ZD101 9-880-924-01 ZENER DIODE RD5.1
ZD102 9-880-925-01 ZENER DIODE RD24JSB3T
ZD103 9-880-926-01 VOLTAGE SUPRESSOR P6KE350CA
MISCELLANEOUS
***************
!14 1-777-854-21 CORD, POWER
19 1-762-844-21 SWITCH, ROTARY (30,45:EE)
!25 1-770-019-12 ADAPTOR, CONVERSION PLUG 3P
!52 1-468-271-31 POWER BLOCK ETXNY165E1D
704 1-500-144-11 HEAD, FE
704 1-500-471-11 HEAD, FE
776 1-759-791-11 DRUM ASSY, DZH-78D-R
(10/X10/20:VP1,VP2/25:B/30:EE)
776 1-759-793-11 DRUM ASSY, DZH-92B-R
(20:EX,UX/25:CP,VC/X25/30:CP,UX,VC1,VC2,X25)
776 1-759-795-11 DRUM ASSY, DZH-93B-R (40/X40/45)
832 1-766-723-21 CONNECTOR, BOARD TO BOAR 3P
M902 1-698-971-11 MOTOR, DC
M903 X-3947-577-1 MOTOR ASSY, CAM
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-418-007-11 COMMANDER, STANDARD (RMT-V256)
(10,X10,30:EE)
1-418-007-21 COMMANDER, STANDARD(RMT-V256A)(40:EE)
1-418-008-11 COMMANDER, STANDARD (RMT-V257)
(20:VP1,VP2)
1-418-008-21 COMMANDER, STANDARD (RMT-V257A) (25:B)
1-418-008-31 COMMANDER, STANDARD (RMT-V257B)
(EG/20:EX,UX/25:CP,VC,X25,40:CP,EG,VC1,VC2/X40)
1-418-008-41 COMMANDER, STANDARD (RMT-V257C) (40:B)
1-418-010-11 COMMANDER, STANDARD (RMT-V259)
(30:CP,UX,VC2,VC1/45)
1-696-593-11 CORD,CONNECTION (PAL) (FOR RF 1.5m)
3-865-171-11 MANUAL, INSTRUCTION( FRENCH) (10:AE1)
3-865-171-21 MANUAL, INSTRUCTION (SPANISH) (10:AE2)
3-865-171-31 MANUAL, INSTRUCTION (GERMAN) (10:AE1)
3-865-171-41 MANUAL, INSTRUCTION (ITALIAN) (10:AE1)
3-865-171-51 MANUAL, INSTRUCTION (DUTCH) (10:AE1)
3-865-171-61 MANUAL, INSTRUCTION (PORTUGUESE)
(10:AE2)
3-865-172-11 MANUAL, INSTRUCTION (SWEDISH) (10:AE2)
3-865-172-21 MANUAL, INSTRUCTION (DANISH) (10:AE2)
3-865-172-31 MANUAL, INSTRUCTION (FINNISH) (10:AE2)
3-865-172-41 MANUAL, INSTRUCTION (GREEK) (10:AE1)
3-865-173-11 MANUAL, INSTRUCTION (ENGLISH) (40:EG)
3-865-173-21 MANUAL, INSTRUCTION (POLISH) (40:EG)
3-865-173-31 MANUAL, INSTRUCTION (CZECH) (40:EG)
3-865-173-41 MANUAL, INSTRUCTION (HUNGARIAN) (40:EG)
3-865-174-11 MANUAL, INSTRUCTION (ENGLISH)
(10:EG,X10)
3-865-174-21 MANUAL, INSTRUCTION (POLISH) (10:EG,X10)
3-865-174-31 MANUAL, INSTRUCTION (HUNGARIAN)
(10:EG,X10)
3-865-174-41 MANUAL, INSTRUCTION (HUNGARIAN)
(10:EG,X10)
3-865-175-11 MANUAL, INSTRUCTION (ENGLISH)
(10:EE/40:EE)
3-865-175-21 MANUAL, INSTRUCTION (RUSSIAN)
(10:EE/40:EE)
3-865-274-11 MANUAL, INSTRUCTION (ENGLISH) (30:EE)
3-865-274-21 MANUAL, INSTRUCTION (RUSSIAN) (30:EE)
3-865-275-11 MANUAL, INSTRUCTION (ENGLISH) (X40)
3-865-275-21 MANUAL, INSTRUCTION (POLISH) (X40)
3-865-275-31 MANUAL, INSTRUCTION (CZECH) (X40)
3-865-275-41 MANUAL, INSTRUCTION (HUNGARIAN) (X40)
3-865-359-11 MANUAL, INSTRUCTION (FRENCH)
(30:VC1/45:VC)
3-865-359-21 MANUAL, INSTRUCTION (SPANISH) (30:CP)
3-865-359-31 MANUAL, INSTRUCTION (GERMAN)
(30:VC1/45:VC)
3-865-359-41 MANUAL, INSTRUCTION (ITALIAN)
(30:CP/45:CP,VC1)
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
