Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
22
SPP-A1070/A1071
BASE MAIN
EC11 1-126-933-11 ELECT 100uF 20% 16V
EC12 1-126-964-11 ELECT 10uF 20% 50V
EC13 1-126-964-11 ELECT 10uF 20% 50V
EC14 1-126-935-11 ELECT 470uF 20% 6.3V
< FUSE >
0F1 1-533-842-11 FUSE (250mA/250V)
< JACK >
J1 1-565-999-11 JACK, MODULAR 2P (LINE)
J3 1-779-215-11 JACK, DC (DC IN 9V)
< COIL >
0L1 1-408-117-00 INDUCTOR 10uH
0L2 1-408-117-00 INDUCTOR 10uH
L3 1-408-117-00 INDUCTOR 10uH
L4 1-408-117-00 INDUCTOR 10uH
L5 1-408-117-00 INDUCTOR 10uH
L6 1-408-117-00 INDUCTOR 10uH
L7 1-408-117-00 INDUCTOR 10uH
L8 1-408-117-00 INDUCTOR 10uH
< TRANSISTOR >
Q1 T-941-615-31 TRANSISTOR MMBT3904LT1
Q2 8-729-026-07 TRANSISTOR MMBT3906LT1
Q3 8-729-026-07 TRANSISTOR MMBT3906LT1
Q4 T-941-615-31 TRANSISTOR MMBT3904LT1
Q5 T-941-615-31 TRANSISTOR MMBT3904LT1
Q6 T-941-615-31 TRANSISTOR MMBT3904LT1
Q7 8-729-026-07 TRANSISTOR MMBT3906LT1
Q8 T-941-615-31 TRANSISTOR MMBT3904LT1
Q9 T-941-615-31 TRANSISTOR MMBT3904LT1
Q10 8-729-026-07 TRANSISTOR MMBT3906LT1
Q11 8-729-026-07 TRANSISTOR MMBT3906LT1
Q12 8-729-026-07 TRANSISTOR MMBT3906LT1
Q13 T-941-615-31 TRANSISTOR MMBT3904LT1
< RESISTOR >
R1 1-216-797-11 METAL CHIP 10 5% 1/16W
R2 1-216-815-11 METAL CHIP 330 5% 1/16W
R3 1-218-311-11 RES-CHIP 390 1% 1/16W
R4 1-218-301-11 RES-CHIP 3.9K 1% 1/16W
R5 1-218-298-11 RES-CHIP 2.2K 1% 1/16W
R6 1-216-807-11 METAL CHIP 68 5% 1/16W
R7 1-218-355-11 RES-CHIP 75K 1% 1/16W
R8 1-216-843-11 METAL CHIP 68K 5% 1/16W
R9 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R10 1-216-864-11 METAL CHIP 0 5% 1/16W
R11 1-218-484-11 METAL CHIP 750 5% 1/16W
R12 1-218-300-11 RES-CHIP 3.3K 1% 1/16W
R14 1-218-349-11 METAL CHIP 240K 5% 1/16W
R15 1-218-272-11 METAL CHIP 5.1K 5% 1/16W
R16 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R17 1-218-455-11 RES-CHIP 62K 1% 1/16W
R18 1-218-347-11 METAL CHIP 91K 5% 1/16W
R19 1-216-835-11 METAL CHIP 15K 5% 1/16W
R20 1-216-833-11 METAL CHIP 10K 5% 1/16W
R21 1-220-933-11 METAL CHIP 220K 1% 0.063W
R22 1-218-306-11 METAL CHIP 100K 1% 1/16W
R23 1-216-843-11 METAL CHIP 68K 5% 1/16W
R24 1-249-608-11 CARBON 220K 5% 1/4W
R25 1-249-608-11 CARBON 220K 5% 1/4W
R26 1-211-893-11 METAL 4.7M 10% 1/4W
R27 1-211-893-11 METAL 4.7M 10% 1/4W
R28 1-240-225-11 RES-CHIP 48.7K 0.1% 1/16W
R29 1-240-225-11 RES-CHIP 48.7K 0.1% 1/16W
R30 1-218-306-11 METAL CHIP 100K 1% 1/16W
R31 1-218-322-11 METAL CHIP 47K 1% 1/16W
R32 1-216-849-11 METAL CHIP 220K 5% 1/16W
R33 1-216-864-11 METAL CHIP 0 5% 1/16W
R34 1-216-865-11 METAL CHIP 3K 5% 1/16W
R35 1-216-865-11 METAL CHIP 3K 5% 1/16W
R36 1-249-510-11 CARBON 18 5% 1/4W
R37 1-216-833-11 METAL CHIP 10K 5% 1/16W
R38 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R39 1-216-837-11 METAL CHIP 22K 5% 1/16W
R40 1-218-331-11 METAL CHIP 51K 5% 1/16W
R41 1-218-331-11 METAL CHIP 51K 5% 1/16W
R42 1-218-331-11 METAL CHIP 51K 5% 1/16W
R43 1-218-455-11 RES-CHIP 62K 1% 1/16W
R44 1-218-320-11 RES-CHIP 15K 1% 1/16W
R45 1-216-841-11 METAL CHIP 47K 5% 1/16W
R46 1-216-845-11 METAL CHIP 100K 5% 1/16W
R47 1-216-833-11 METAL CHIP 10K 5% 1/16W
R48 1-216-833-11 METAL CHIP 10K 5% 1/16W
R49 1-216-833-11 METAL CHIP 10K 5% 1/16W
R50 1-218-288-11 METAL CHIP 300 5% 1/16W
R51 1-216-821-11 METAL CHIP 1K 5% 1/16W
R52 1-216-801-11 METAL CHIP 22 5% 1/16W
0 R54 1-249-608-11 CARBON 220K 5% 1/4W
0 R55 1-249-608-11 CARBON 220K 5% 1/4W
0 R56 1-211-893-11 METAL 4.7M 10% 1/4W
0 R57 1-220-787-11 METAL 5.1M 5% 1/16W
R58 1-216-857-11 METAL CHIP 1M 5% 1/16W
R60 1-249-506-11 CARBON 12 5% 1/4W
R61 1-216-833-11 METAL CHIP 10K 5% 1/16W
R62 1-216-865-11 METAL CHIP 3K 5% 1/16W
R63 1-216-837-11 METAL CHIP 22K 5% 1/16W
R64 1-216-833-11 METAL CHIP 10K 5% 1/16W
R65 1-216-809-11 METAL CHIP 100 5% 1/16W
R67 1-216-864-11 METAL CHIP 0 5% 1/16W
R68 1-211-895-11 METAL 10M 10% 1/4W
R69 1-211-895-11 METAL 10M 10% 1/4W
R70 1-219-570-11 METAL CHIP 10M 5% 1/16W
R71 1-219-570-11 METAL CHIP 10M 5% 1/16W
R72 1-242-957-11 RES-CHIP 5.6M 5% 1/16W
R73 1-216-835-11 METAL CHIP 15K 5% 1/16W
R74 1-242-957-11 RES-CHIP 5.6M 5% 1/16W
R75 1-216-839-11 METAL CHIP 33K 5% 1/16W
R76 1-216-833-11 METAL CHIP 10K 5% 1/16W
R77 1-216-839-11 METAL CHIP 33K 5% 1/16W
R78 1-216-839-11 METAL CHIP 33K 5% 1/16W
R79 1-249-947-11 CARBON 10K 5% 1/4W
R80 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R81 1-216-848-11 METAL CHIP 180K 5% 1/16W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
