SPP-A1070/A1071
SECTION 7
ELECTRICAL PARTS LIST
BASE KEY
BASE MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-682-704-11 BASE KEY BOARD
***************
< CAPACITOR >
C1 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< LED >
LED1 8-719-059-40 LED SLR-342VR3F (ANSWER ON/OFF)
LED2 8-719-064-51 LED SLA-360JT3F (MAIL BOX 1, PLAY/STOP)
LED3 8-719-064-51 LED SLA-360JT3F (2)
LED4 8-719-064-51 LED SLA-360JT3F (3)
LED5 8-719-064-51 LED SLA-360JT3F (CHARGE)
LED6 8-719-081-87 LED SLA-360MT3F (LINE)
LED7 8-719-064-51 LED SLA-360JT3F (NEW CALL)
U1 8-719-803-22 LED TLR322 (MESSAGE COUNTER)
**************************************************************
* A-3062-656-A BASE MAIN BOARD, COMPLETE
**************************
< CAPACITOR >
C2 1-125-779-21 CERAMIC CHIP 0.022uF
C3 1-125-779-21 CERAMIC CHIP 0.022uF
C6 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C8 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C9 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C10 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C11 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C12 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
0 C13 1-162-114-00 CERAMIC 0.0047uF 2KV
0 C14 1-162-114-00 CERAMIC 0.0047uF 2KV
C15 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C16 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C17 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C18 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C19 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C20 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C21 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C22 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C23 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C24 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C25 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C26 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C27 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C28 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C29 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C30 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C31 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C32 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C33 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C34 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C35 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
0 C36 1-136-193-11 MYLAR 0.47uF 5% 250V
C37 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C39 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C40 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C41 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C42 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C43 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C44 1-164-346-11 CERAMIC CHIP 1uF 16V
C48 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
< DIODE/VARISTOR >
0 D1 8-719-029-30 DIODE BAS16
0 D2 8-719-029-30 DIODE BAS16
0 D3 8-719-029-30 DIODE BAS16
0 D4 8-719-029-30 DIODE BAS16
D5 8-719-909-90 DIODE BAV99
0 D6 1-801-730-11 VARISTOR
D7 8-719-820-05 DIODE 1SS181
0 D8 8-719-110-72 DIODE RD30ESB2
0 D9 8-719-110-72 DIODE RD30ESB2
D10 8-719-055-76 DIODE 1N4148
D11 8-719-055-76 DIODE 1N4148
D12 8-719-909-90 DIODE BAV99
< CAPACITOR >
EC1 1-126-933-11 ELECT 100uF 20% 16V
EC2 1-126-961-11 ELECT 2.2uF 20% 50V
EC3 1-126-963-11 ELECT 4.7uF 20% 50V
EC4 1-126-963-11 ELECT 4.7uF 20% 50V
EC5 1-126-933-11 ELECT 100uF 20% 16V
EC6 1-126-935-11 ELECT 470uF 20% 6.3V
EC7 1-126-961-11 ELECT 2.2uF 20% 50V
EC8 1-126-935-11 ELECT 470uF 20% 6.3V
EC9 1-126-947-11 ELECT 47uF 20% 16V
EC10 1-126-964-11 ELECT 10uF 20% 50V
