Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
24
SPP-A1070/A1071
< RESISTOR >
R1 1-216-845-11 METAL CHIP 100K 5% 1/16W
R2 1-216-845-11 METAL CHIP 100K 5% 1/16W
R3 1-216-821-11 METAL CHIP 1K 5% 1/16W
R4 1-216-799-11 METAL CHIP 15 5% 1/16W
R5 1-216-821-11 METAL CHIP 1K 5% 1/16W
R6 1-218-917-11 METAL CHIP 820K 0.5% 1/16W
R7 1-216-854-11 METAL CHIP 560K 5% 1/16W
R8 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R9 1-216-845-11 METAL CHIP 100K 5% 1/16W
R10 1-216-857-11 METAL CHIP 1M 5% 1/16W
R11 1-216-841-11 METAL CHIP 47K 5% 1/16W
R12 1-218-344-11 METAL CHIP 7.5K 5% 1/16W
R14 1-216-839-11 METAL CHIP 33K 5% 1/16W
R15 1-216-800-11 METAL CHIP 18 5% 1/16W
R16 1-220-373-11 METAL CHIP 620 5% 1/16W
R17 1-216-798-11 METAL CHIP 12 5% 1/16W
R18 1-216-798-11 METAL CHIP 12 5% 1/16W
R22 1-216-845-11 METAL CHIP 100K 5% 1/16W
R23 1-216-845-11 METAL CHIP 100K 5% 1/16W
R24 1-218-292-11 METAL CHIP 20K 5% 1/16W
R25 1-218-292-11 METAL CHIP 20K 5% 1/16W
R26 1-216-841-11 METAL CHIP 47K 5% 1/16W
R27 1-216-845-11 METAL CHIP 100K 5% 1/16W
R28 1-216-845-11 METAL CHIP 100K 5% 1/16W
R29 1-216-845-11 METAL CHIP 100K 5% 1/16W
R30 1-216-845-11 METAL CHIP 100K 5% 1/16W
R31 1-216-845-11 METAL CHIP 100K 5% 1/16W
R32 1-216-845-11 METAL CHIP 100K 5% 1/16W
R33 1-216-857-11 METAL CHIP 1M 5% 1/16W
R34 1-216-864-11 METAL CHIP 0 5% 1/16W
R35 1-216-851-11 METAL CHIP 330K 5% 1/16W
R37 1-216-845-11 METAL CHIP 100K 5% 1/16W
R38 1-216-845-11 METAL CHIP 100K 5% 1/16W
R40 1-216-864-11 METAL CHIP 0 5% 1/16W
R41 1-216-841-11 METAL CHIP 47K 5% 1/16W
R42 1-216-797-11 METAL CHIP 10 5% 1/16W
R43 1-216-864-11 METAL CHIP 0 5% 1/16W
R44 1-216-805-11 METAL CHIP 47 5% 1/16W
R45 1-216-833-11 METAL CHIP 10K 5% 1/16W
R46 1-216-798-11 METAL CHIP 12 5% 1/16W
(A1071)
R47 1-216-798-11 METAL CHIP 12 5% 1/16W
(A1071)
R54 1-216-835-11 METAL CHIP 15K 5% 1/16W
R55 1-216-839-11 METAL CHIP 33K 5% 1/16W
R57 1-216-821-11 METAL CHIP 1K 5% 1/16W
< SWITCH >
SW1 1-571-188-21 SWITCH, TACTILE (REFLOW TYPE)
(VOL V CID)
SW2 1-571-188-21 SWITCH, TACTILE (REFLOW TYPE)
(VOL v DIR)
< IC >
U2 6-800-573-01 IC TMP87C807U-3CR4
U3 6-701-032-01 IC PQ1R23
U4 X-3381-019-1 EEROM ASSY
HAND MAIN
< VIBRATOR >
X1 1-760-627-11 VIBRATOR, CRYSTAL (32.768kHz)
X2 1-567-918-21 VIBRATOR, CERAMIC (8MHz)
************************************************************
MISCELLANEOUS
**************
LCD1 1-804-511-11 LCD MODULE (H/S)
BUZ1 1-544-603-11 BUZZER
MIC1 1-542-260-31 MICROPHONE, ELECTRET CONDENSER
MIC101 1-542-260-31 MICROPHONE, ELECTRET CONDENSER
SP1 1-505-593-11 SPEAKER (2.8cm)
SP101 1-544-035-11 SPEAKER (5cm)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-103-19 SCREW +P 2X5 TYPE2 NON-SLIT
#2 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#3 7-685-547-19 SCREW +BTP 3X10 TYPE2 N-S
#4 7-685-648-79 SCREW +P 3X12 TYPE2 NON-SLIT
#5 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-475-852-11 ADAPTOR, AC (AC-T122)
1-528-813-11 BATTERY PACK (BP-T18)
1-696-454-11 CORD (WITH MODULAR PLUG) (LINE)
3-230-071-01 CASE (WALL HOOK)
3-230-541-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH)
(A1070)
3-230-541-21 MANUAL, INSTRUCTION (ENGLISH) (A1071)
3-230-541-31 MANUAL, INSTRUCTION (FRENCH) (A1071)
3-230-542-11 GUIDE, QUICK START (ENGLISH, SPANISH)
(A1070)
3-230-542-21 GUIDE, QUICK START (ENGLISH, FRENCH)
(A1071)
3-230-543-11 CARD, REMOTE CONTROL
(ENGLISH, SPANISH) (A1070)
3-230-543-21 CARD, REMOTE CONTROL
(ENGLISH, FRENCH) (A1071)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
