Help Guide
Multi Channel AV Receiver
STR-AZ1000ES
Installing 5.1.2-channel speaker system using front Dolby Atmos enabled speakers
You can enjoy vertical surround effects by connecting additional two front Dolby Atmos enabled speakers.
Angle at which each speaker is placed from the line connecting the listening position and the center speaker (0
degrees)
Front Dolby Atmos enabled speakers: 30°
Surround speakers: 100° - 120°
Hint
As the subwoofer does not emit highly directional signals, you can place it wherever you want.
Related Topic
Speaker installation example
Connecting 5.1.2-channel speaker system using front Dolby Atmos enabled speakers
5-037-020-11(1) Copyright 2022 Sony Corporation
