Regulatory Information
Declaration of Conformity
Trade name: SONY
Model No.: STR-DA5000ES/STR-DA3000ES
Responsible Party: Sony Electronics Inc.
Address: 680 Kinderkamack Road, Oradell NJ
07649 U.S.A.
Telephone No.: 201-930-6972
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
For customer in Canada
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
Except for European model
ENERGY STAR® is a U.S. registered
mark. As an ENERGY STAR®
partner, Sony Corporation has
determined that this product meets the
ENERGY STAR® guidelines for
energy efficiency.
About This Manual
The instructions in this manual are for model STR-
DA5000ES and STR-DA3000ES. Check your model
number by looking at the lower right corner of the
front panel. In this manual, STR-DA3000ES (area
code CEL) is used for illustration purposes unless
stated otherwise. Any difference in operation is
clearly indicated in the text, for example, “STR-
DA5000ES only”.
The instructions in this manual describe the controls
on the receiver. You can also use the controls on the
supplied remote if they have the same or similar
names as those on the receiver. For details on the use
of your remote, see the separate operating
instructions supplied with the remote.
STR-DA5000ES
RM-LJ312
STR-DA3000ES
RM-LG112
STR-DA5000ES/STR-DA3000ES
Models of area code U,CA only
RM-US106
This receiver incorporates Dolby* Digital and Pro
Logic Surround and the DTS** Digital Surround
System.
* Manufactured under license from Dolby
Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories.
**“DTS”, “DTS-ES Extended Surround”, and
“Neo:6” are trademarks of Digital Theater Systems,
Inc.
About area codes
The area code of the receiver you purchased is
shown on the upper left portion of the rear panel
(see the illustration below).
Any differences in operation, according to the area
code, are clearly indicated in the text, for example,
“Models of area code AA only”.
4-XXX-XXX-XX AA
SURROUND BACK SPE
CTRL
A1
DIGITAL
CENTER
SURR BACK
SUB
WOOFER
SURROUND
FRONT
ASSIGNABLE
DVD
COAXIAL
IN
CD/SACD
COAXIAL
IN
DVD
OPTICAL
IN
TV/SAT
OPTICAL
IN
CD/SACD
OPTICAL
IN
MD/DAT
OPTICAL
IN
MD/DAT
OPTICAL
OUT
FRONT
R
R
R
L
IMPEDANCE USE 4-16
AM
FM
U
PRE OUT
MULTI CHANNEL
INPUT 2
75 COAXIAL
ANTENNA
RS232C
Area code
