STR-DA3000ES: FRONT
2)
: 200 W + 200 W
CENTER
2)
: 200 W
SURR
2)
: 200 W + 200 W
SURR BACK
2)
: 200 W + 200
W
1) Depending on the sound field settings and the
source, there may be no sound output.
2) Measured under the following conditions:
3) Models of area code U, CA only.
4) Models of area code TW only.
Frequency response
Inputs (Analog)
Inputs (Digital)
Outputs
EQUALIZER
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Useable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range
Models of area code U, CA:
530 – 1,710 kHz
5)
(With 10-kHz tuning scale)
531 – 1,710 kHz
5)
(With 9-kHz tuning scale)
Models of other area codes:
531 – 1,602 kHz
(With 9-kHz tuning scale)
Antenna Loop antenna
Usable sensitivity 50 dB/m (at 1,000 kHz or 999
kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity
At 9 kHz: 35 dB
At 10 kHz: 40 dB
5) You can change the AM tuning scale to 9 kHz or 10
kHz. After tuning in any AM station, turn off the
Area code Power requirements
U, CA 120 V AC, 60 Hz
TW 110 V AC, 60 Hz
CEL 230 V AC, 50/60 Hz
CN 220-230 V AC, 50/60 Hz
KR 220 V AC, 60 Hz
PHONO RIAA equalization curve
±0.5 dB
MULTI CHANNEL
INPUT 1, 2, CD/
SACD, TAPE, MD/
DAT, DVD, TV/SAT,
VIDEO 1, 2, 3
10 Hz – 40 kHz
±3 dB (when sound field and
equalizer bypassed)
PHONO S/N: 86 dB
MULTI CHANNEL
INPUT 1, 2, CD/
SACD, TAPE, MD/
DAT, DVD, TV/SAT,
VIDEO 1, 2, 3
S/N: 96 dB
CD/SACD, DVD
(Coaxial)
S/N: 96 dB
(A, 20 kHz LPF)
CD/SACD, DVD, TV/
SAT, MD/DAT,
VIDEO3 (Optical)
S/N: 96 dB
(A, 20 kHz LPF)
TAPE, MD/DAT
(REC OUT), VIDEO
1, 2 (AUDIO OUT)
FRONT L/R,
CENTER,
SURROUND L/R,
SURROUND BACK
(L/R), SUB WOOFER
Gain levels ±10 dB, 1 dB step
continued
