42
STR-DB900
DISPLAY BOARD IC802 uPD16315GB-3BS (FL DRIVER)
Pin No. Pin Name I/O Description
1AUX LED O Not used. (Open)
2 TV LED O Not used. (Open)
3DVD LED O Not used. (Open)
4 VIDEO LED O Not used. (Open)
5 OSC — Clock OSC set terminal
6 DOUT O Not used. (Open)
7DIN I Serial data input from MB91354APMT
8 CLK I Serial clock input from MB91354APMT
9 STB I Strobe signal input from MB91356APMT
10 KEY1 I Not used. (Connected to ground)
11 KEY2 I Not used. (Connected to ground)
12 VSS — Ground
13 VDD — Power supply (+5 V)
14 to 29 SEG1 to SEG16 O FLD segment output
30 VEE — Power supply (-30 V)
31 to 42 GRID10 to GRIG1 O FLD grid output
43 VDD — Power supply (+5 V)
44 VSS — Ground
