Sony STR-DB900 Service Manual

46
STR-DB900
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• Accessories are given in the last of this parts
list.
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC SW BOARD
************
< CONNECTOR >
* CN1 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< SWITCH >
0 S1 1-692-349-11 SWITCH, PUSH (AC POWER) (POWER)
************************************************************
A-4752-839-A AMP BOARD, COMPLETE
********************
< CAPACITOR >
C201 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C300 1-112-031-11 ELECT (BLOCK) 8200uF 20% 63V
C301 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C302 1-135-671-51 ELECT 2200uF 10V
C303 1-125-926-11 TANTAL. CHIP 4.7uF 20% 6.3V
C304 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C305 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C306 1-125-926-11 TANTAL. CHIP 4.7uF 20% 6.3V
C307 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C308 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C309 1-125-926-11 TANTAL. CHIP 4.7uF 20% 6.3V
C310 1-128-871-91 ELECT 47uF 20% 63V
C311 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C312 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C313 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C314 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C315 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C316 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C317 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C318 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C319 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C320 1-127-725-91 ELECT 220PF 20% 25V
C321 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C322 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C323 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C324 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C325 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C326 1-127-725-91 ELECT 220PF 20% 25V
C327 1-127-725-91 ELECT 220PF 20% 25V
C328 1-127-725-91 ELECT 220PF 20% 25V
C329 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C330 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C331 1-128-875-11 ELECT 470uF 20% 63V
C332 1-128-875-11 ELECT 470uF 20% 63V
C333 1-128-872-91 ELECT 100uF 20% 63V
C335 1-100-598-11 MYLAR 1uF 5% 250V
C336 1-100-598-11 MYLAR 1uF 5% 250V
C337 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C338 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C339 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C340 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C341 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C342 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C343 1-127-725-91 ELECT 220PF 20% 25V
C344 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C345 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C346 1-128-875-11 ELECT 470uF 20% 63V
C347 1-128-875-11 ELECT 470uF 20% 63V
C348 1-128-872-91 ELECT 100uF 20% 63V
C349 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C350 1-100-623-91 CERAMIC CHIP 0.1uF 10% 100V
C351 1-100-623-91 CERAMIC CHIP 0.1uF 10% 100V
C353 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C354 1-100-598-11 MYLAR 1uF 5% 250V
C355 1-100-598-11 MYLAR 1uF 5% 250V
C356 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C357 1-100-623-91 CERAMIC CHIP 0.1uF 10% 100V
C358 1-127-725-91 ELECT 220PF 20% 25V
C359 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C360 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C363 1-128-871-91 ELECT 47uF 20% 63V
C364 1-125-926-11 TANTAL. CHIP 4.7uF 20% 6.3V
C365 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C366 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C367 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C368 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C369 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C370 1-135-671-51 ELECT 2200uF 10V
C371 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C372 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C373 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C374 1-125-926-11 TANTAL. CHIP 4.7uF 20% 6.3V
C375 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C376 1-165-319-11 CERAMIC CHIP 0.1uF 50V
AC SW
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
AMP
•Abbreviation
SP : Singapore model
MY : Malaysia model
