53
STR-DB900
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R535 1-216-797-11 METAL CHIP 10 5% 1/10W
R536 1-216-797-11 METAL CHIP 10 5% 1/10W
R537 1-216-797-11 METAL CHIP 10 5% 1/10W
R538 1-216-797-11 METAL CHIP 10 5% 1/10W
R539 1-216-797-11 METAL CHIP 10 5% 1/10W
R540 1-216-797-11 METAL CHIP 10 5% 1/10W
R541 1-216-797-11 METAL CHIP 10 5% 1/10W
R542 1-216-797-11 METAL CHIP 10 5% 1/10W
R543 1-216-797-11 METAL CHIP 10 5% 1/10W
R544 1-216-797-11 METAL CHIP 10 5% 1/10W
R545 1-216-797-11 METAL CHIP 10 5% 1/10W
R546 1-216-797-11 METAL CHIP 10 5% 1/10W
R547 1-216-797-11 METAL CHIP 10 5% 1/10W
R548 1-216-797-11 METAL CHIP 10 5% 1/10W
R549 1-216-797-11 METAL CHIP 10 5% 1/10W
R550 1-216-797-11 METAL CHIP 10 5% 1/10W
R551 1-216-797-11 METAL CHIP 10 5% 1/10W
R552 1-216-797-11 METAL CHIP 10 5% 1/10W
R553 1-216-797-11 METAL CHIP 10 5% 1/10W
R554 1-216-797-11 METAL CHIP 10 5% 1/10W
R555 1-216-797-11 METAL CHIP 10 5% 1/10W
R556 1-216-797-11 METAL CHIP 10 5% 1/10W
R557 1-216-809-11 METAL CHIP 100 5% 1/10W
R558 1-216-809-11 METAL CHIP 100 5% 1/10W
R559 1-216-809-11 METAL CHIP 100 5% 1/10W
R560 1-216-809-11 METAL CHIP 100 5% 1/10W
R561 1-216-809-11 METAL CHIP 100 5% 1/10W
R562 1-216-809-11 METAL CHIP 100 5% 1/10W
0 R563 1-217-477-00 FUSIBLE 4.7 5% 1W
R601 1-216-815-11 METAL CHIP 330 5% 1/10W
R602 1-216-808-11 METAL CHIP 82 5% 1/10W
R603 1-216-813-11 METAL CHIP 220 5% 1/10W
R604 1-216-835-11 METAL CHIP 15K 5% 1/10W
R605 1-216-797-11 METAL CHIP 10 5% 1/10W
R606 1-216-797-11 METAL CHIP 10 5% 1/10W
R607 1-216-797-11 METAL CHIP 10 5% 1/10W
R608 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R609 1-216-803-11 METAL CHIP 33 5% 1/10W
R610 1-216-815-11 METAL CHIP 330 5% 1/10W
R611 1-216-815-11 METAL CHIP 330 5% 1/10W
R612 1-216-815-11 METAL CHIP 330 5% 1/10W
R613 1-216-815-11 METAL CHIP 330 5% 1/10W
R614 1-216-810-11 METAL CHIP 120 5% 1/10W
R615 1-216-797-11 METAL CHIP 10 5% 1/10W
R616 1-216-797-11 METAL CHIP 10 5% 1/10W
R617 1-216-810-11 METAL CHIP 120 5% 1/10W
R618 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R619 1-216-864-11 SHORT CHIP 0
R620 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R621 1-216-864-11 SHORT CHIP 0
0 R624 1-243-961-21 METAL CHIP 0.1 5% 1W
0 R625 1-243-961-21 METAL CHIP 0.1 5% 1W
R627 1-216-833-11 METAL CHIP 10K 5% 1/10W
R628 1-218-269-11 METAL CHIP 360 5% 1/10W
R629 1-216-849-11 METAL CHIP 220K 5% 1/10W
R630 1-216-849-11 METAL CHIP 220K 5% 1/10W
R631 1-216-844-11 METAL CHIP 82K 5% 1/10W
R632 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R636 1-216-815-11 METAL CHIP 330 5% 1/10W
R637 1-216-809-11 METAL CHIP 100 5% 1/10W
< RELAY >
RY301 1-515-614-11 RELAY
RY302 1-515-614-11 RELAY
< THERMISTOR >
THP301 1-805-359-21 THERMISTOR (2012)
THP302 1-805-359-21 THERMISTOR (2012)
THP303 1-805-359-21 THERMISTOR (2012)
THP304 1-805-359-21 THERMISTOR (2012)
THP305 1-805-359-21 THERMISTOR (2012)
THP601 1-805-359-21 THERMISTOR (2012)
< TERMINAL >
TM301 1-780-023-11 TERMINAL BOARD (SPEAKER) (FRONT L)
TM302 1-780-023-11 TERMINAL BOARD (SPEAKER) (FRONT R)
TM303 1-780-023-11 TERMINAL BOARD (SPEAKER) (CENTER)
TM304 1-780-023-11 TERMINAL BOARD (SPEAKER) (SURROUND L)
TM305 1-780-023-11 TERMINAL BOARD (SPEAKER) (SURROUND R)
TM601 1-780-023-11 TERMINAL BOARD (SPEAKER)
(SURROUND BACK)
< VIBRATOR >
X300 1-795-660-21 QUARTZ CRYSTAL UNIT (49.1MHz)
************************************************************
A-1070-925-A ANALOG IN BOARD, COMPLETE (SP, MY)
A-4752-844-A ANALOG IN BOARD, COMPLETE (AEP, UK)
*************************
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(AEP, UK)
C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP, UK)
C104 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C107 1-119-824-11 ELECT 10uF 20% 50V
C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C109 1-127-718-91 ELECT 100uF 20% 16V
C110 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C111 1-119-823-11 ELECT 4.7uF 20% 50V
C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C113 1-128-844-11 ELECT 33uF 20% 25V
C114 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C115 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C116 1-128-844-11 ELECT 33uF 20% 25V
C117 1-119-799-11 ELECT 47uF 20% 25V
C118 1-119-824-11 ELECT 10uF 20% 50V
C119 1-119-824-11 ELECT 10uF 20% 50V
C120 1-128-844-11 ELECT 33uF 20% 25V
C121 1-119-823-11 ELECT 4.7uF 20% 50V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
AMP ANALOG IN
