56
STR-DB900
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C248 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C249 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C250 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C251 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C252 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C253 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C254 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C256 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C258 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C259 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C260 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C261 1-119-824-11 ELECT 10uF 20% 50V
C262 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C263 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C264 1-117-370-11 CERAMIC CHIP 10uF 10V
C266 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C267 1-119-799-11 ELECT 47uF 20% 25V
C268 1-119-799-11 ELECT 47uF 20% 25V
C269 1-119-799-11 ELECT 47uF 20% 25V
C270 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C271 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C273 1-128-832-11 ELECT 220uF 20% 10V
C274 1-127-718-91 ELECT 100uF 20% 16V
(SP, MY)
C274 1-128-861-11 ELECT 100uF 20% 50V
(AEP, UK)
C276 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C278 1-119-799-11 ELECT 47uF 20% 25V
C279 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C280 1-119-825-11 ELECT 22uF 20% 50V
C281 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C282 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C283 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C284 1-119-822-11 ELECT 3.3uF 20% 50V
C285 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C286 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C288 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C289 1-117-370-11 CERAMIC CHIP 10uF 10V
C290 1-128-832-11 ELECT 220uF 20% 10V
C291 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C292 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C293 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C294 1-128-832-11 ELECT 220uF 20% 10V
C295 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C297 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN201 1-784-778-11 CONNECTOR, FFC 17P
CN202 1-778-867-21 CONNECTOR, FFC/FPC 6P
CN203 1-784-784-11 CONNECTOR, FFC 23P
CN207 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
CN209 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-988-61 DIODE 1SS355TE-17
D301 8-719-016-74 DIODE 1SS352
D302 8-719-016-74 DIODE 1SS352
D303 8-719-016-74 DIODE 1SS352
< EARTH TERMINAL >
* EP201 1-537-738-21 TERMINAL, EARTH
* EP202 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB201 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB202 1-469-450-21 INDUCTOR, FERRITE BEAD (3225)
FB203 1-469-450-21 INDUCTOR, FERRITE BEAD (3225)
FB204 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB205 1-216-864-11 SHORT CHIP 0
FB206 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB207 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB208 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB209 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB210 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB211 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB212 1-216-295-91 SHORT CHIP 0
< IC >
IC201 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC202 6-804-246-01 IC MB91354APMT-G-104-BNDE1
IC203 6-704-037-01 IC IC61LV6416-15TG
IC204 8-759-680-48 IC TC7WH157FK (TE85R)
IC205 8-759-835-63 IC NJM2391DL1-26 (TE1)
IC206 6-702-047-01 IC CXD9718Q
IC209 6-704-004-01 IC BR24L16F-WE2
IC210 8-759-680-48 IC TC7WH157FK (TE85R)
IC211 8-759-926-17 IC SN74HC153ANS
IC212 6-600-012-11 IC TOTX141L (RED)
(DIGITAL OPTICAL HDD/MD OUT)
IC213 6-600-014-01 IC TORX141L (DIGITAL OPTICAL HDD/MD IN)
IC214 6-600-014-01 IC TORX141L (DIGITAL OPTICAL TV/SAT IN)
IC216 8-759-242-70 IC TC7WU04F
IC217 8-759-825-15 IC LC89056W-E
IC218 6-600-014-01 IC TORX141L (DIGITAL OPTICAL DVD IN)
< JACK >
J201 1-793-446-21 JACK, PIN 1P (DIGITAL COAXIAL DVD IN)
< SHORT >
JR201 1-216-864-11 SHORT CHIP 0 (SP, MY)
JR203 1-216-864-11 SHORT CHIP 0 (SP, MY)
JR204 1-216-864-11 SHORT CHIP 0 (SP, MY)
< COIL >
L201 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q201 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q202 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q203 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q204 8-729-027-43 TRANSISTOR DTC114EKA-T146
DIGITAL
