59
STR-DB900
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< FLUORESCENT INDICATOR >
FL801 1-518-993-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC802 8-759-643-83 IC uPD16315GB-3BS
IC803 8-759-157-94 IC TC74ACT08F (EL)
< COIL >
L801 1-412-963-11 INDUCTOR 100uH
L802 1-410-478-11 INDUCTOR 47uH
< TRANSISTOR >
Q801 8-729-822-05 TRANSISTOR 2SD1622ST-TD-E
Q802 8-729-822-05 TRANSISTOR 2SD1622ST-TD-E
Q803 8-729-901-00 TRANSISTOR DTC124EK
< RESISTOR >
R801 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R802 1-216-833-11 METAL CHIP 10K 5% 1/10W
R803 1-216-817-11 METAL CHIP 470 5% 1/10W
R804 1-216-817-11 METAL CHIP 470 5% 1/10W
R805 1-216-821-11 METAL CHIP 1K 5% 1/10W
R806 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R807 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R808 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R810 1-216-821-11 METAL CHIP 1K 5% 1/10W
R811 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R812 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R813 1-216-844-11 METAL CHIP 82K 5% 1/10W
0 R816 1-249-399-11 CARBON 33 5% 1/4W
R818 1-216-821-11 METAL CHIP 1K 5% 1/10W
< VARIABLE RESISTOR >
RV802 1-467-808-21 ENCODER, ROTARY (INPUT SELECTOR)
< SWITCH >
S802 1-771-349-21 SWITCH, KEYBOARD (MULTI CH IN)
S803 1-771-349-21 SWITCH, KEYBOARD (SOUND FIELD)
S804 1-771-349-21 SWITCH, KEYBOARD (SURR BACK DECODING)
S805 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING +)
S806 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING -)
S807 1-771-349-21 SWITCH, KEYBOARD (INPUT MODE)
S808 1-771-349-21 SWITCH, KEYBOARD (DISPLAY)
S809 1-771-349-21 SWITCH, KEYBOARD (2CH)
S810 1-771-349-21 SWITCH, KEYBOARD (DIRECT)
< TRANSFORMER >
T801 1-443-300-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
HP BOARD
********
< CAPACITOR >
C415 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C416 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C417 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< FERRITE BEAD >
FB401 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB402 1-469-152-11 FERRITE, EMI (SMD) (2012)
< JACK >
J401 1-815-313-11 JACK (PHONES)
************************************************************
LED BOARD
*********
3-362-478-01 HOLDER (T), LED
< CAPACITOR >
C801 1-119-943-91 ELECT 47uF 20% 50V
C815 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< DIODE >
D808 8-719-304-78 DIODE SEL2210R-D (STANDBY)
< IC >
IC801 8-759-826-34 IC NJL74H400A (
)
< RESISTOR >
R809 1-216-809-11 METAL CHIP 100 5% 1/10W
R814 1-216-845-11 METAL CHIP 100K 5% 1/10W
R815 1-216-797-11 METAL CHIP 10 5% 1/10W
R817 1-216-815-11 METAL CHIP 330 5% 1/10W
************************************************************
A-4752-842-A POWER BOARD, COMPLETE
*********************
1-533-293-11 FUSE HOLDER
3-905-609-13 SCREW (TRANSISTOR)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
0C901 1-165-531-11 MYLAR 1uF 10 275V
0C902 1-126-933-11 ELECT 100uF 20% 16V
C903 1-128-582-11 ELECT 10uF 20% 100V
0C904 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0C905 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0C906 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0C907 1-165-530-11 MYLAR 0.47uF 10 275V
C910 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
0C913 1-126-966-11 ELECT 33uF 20% 50V
C914 1-110-622-11 ELECT 1000uF 20% 63V
C915 1-137-150-11 FILM 0.01uF 5% 100V
0C916 1-100-973-11 ELECT (BLOCK) 470uF 20% 450V
C917 1-137-150-11 FILM 0.01uF 5% 100V
C918 1-136-270-11 FILM 47PF 5% 630V
0C919 1-126-965-91 ELECT 22uF 20% 50V
0C920 1-135-623-11 FILM 10000PF 5% 630V
C922 1-136-555-11 FILM 0.0022uF 5% 630V
0C923 1-136-538-11 FILM 0.001uF 3% 2KV
C924 1-117-306-11 ELECT 3300uF 20% 16V
C925 1-117-306-11 ELECT 3300uF 20% 16V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
DISPLAY HP LED POWER
