Sony STR-DE235 - Power Switch, Primary, Secondary, SP SW, Standby, Tone Board Parts

– 47 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R953 1-249-433-11 CARBON 22K 5% 1/4W
R954 1-249-437-11 CARBON 47K 5% 1/4W
R955 1-249-429-11 CARBON 10K 5% 1/4W
R956 1-247-843-11 CARBON 3.3K 5% 1/4W
R957 1-249-417-11 CARBON 1K 5% 1/4W
R960 1-249-431-11 CARBON 15K 5% 1/4W
RR04 1-249-393-11 CARBON 10 5% 1/4W
RR05 1-249-393-11 CARBON 10 5% 1/4W
RR54 1-249-393-11 CARBON 10 5% 1/4W
RR55 1-249-393-11 CARBON 10 5% 1/4W
< RELAY >
RY601 1-515-921-11 RELAY (12V)
RY701 1-515-921-11 RELAY (12V)
RY801 1-755-013-11 RELAY
< TERMINAL >
TM601 1-537-510-11 TERMINAL BOARD (SPEAKER) (6P)
(SPEAKERS CENTER/REAR)
TM701 1-537-376-11 TERMINAL BOARD (SP)
(SPEAKERS FRONT A/B)
< VIBRATOR >
X1 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
************************************************************
1-673-051-11 POWER SWITCH BOARD
********************
< CONNECTOR >
CNS203 1-573-105-11 CONNECTOR, PC BOARD 4P
< SWITCH >
S200 1-762-196-21 SWITCH, TACT (1/u)
************************************************************
1-673-050-11 PRIMARY BOARD
**************
1-533-293-11 FUSE HOLDER
< FUSE >
! F901 1-532-503-11 FUSE (T1.6AL/250V)
************************************************************
1-673-049-11 SECONDARY BOARD
*****************
< CONNECTOR >
CNP801 1-691-773-11 PLUG (MICRO CONNECTOR) 11P
< RESISTOR >
! R810 1-249-381-11 CARBON 1 5% 1/4W F
! R811 1-249-381-11 CARBON 1 5% 1/4W F
************************************************************
1-673-045-11 SP SW BOARD
************
< CONNECTOR >
CNP703 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNP704 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< JACK >
J741 1-750-733-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R741 1-247-753-11 CARBON 1.2K 5% 1/2W
R742 1-247-753-11 CARBON 1.2K 5% 1/2W
R791 1-247-753-11 CARBON 1.2K 5% 1/2W
R792 1-247-753-11 CARBON 1.2K 5% 1/2W
< SWITCH >
S701 1-771-634-11 SWITCH, PUSH (2 KEY)
(SPEAKERS A/B ON/OFF)
************************************************************
1-673-048-11 STANDBY BOARD
**************
1-533-903-21 HOLDER, FUSE (AEP)
< AC OUTLET >
! CNJ903 1-526-794-11 OUTLET, AC (AC OUTLET) (AEP)
< CONNECTOR >
CNP802 1-779-495-11 PLUG, CONNECTOR PIN 4P
CNP901 1-564-321-00 PIN, CONNECTOR 2P
* CNP903 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P (AEP)
< DIODE >
D816 8-719-911-19 DIODE 1SS119
< FUSE >
! F902 1-532-464-51 FUSE (T2.5AL/250V) (AEP)
< RELAY >
! RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
! T902 1-433-685-11 TRANSFORMER, POWER
************************************************************
1-673-044-11 TONE BOARD
***********
< CAPACITOR >
C421 1-137-440-11 FILM 0.018uF 5% 50V
C422 1-124-463-00 ELECT 0.1uF 20% 50V
C423 1-137-368-11 FILM 0.0047uF 5% 50V
C424 1-137-372-11 FILM 0.022uF 5% 50V
C471 1-137-440-11 FILM 0.018uF 5% 50V
C472 1-124-463-00 ELECT 0.1uF 20% 50V
MAIN POWER SWITCH PRIMARY SECONDARY
SP SW STANDBY TONE
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
