– 48 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C473 1-137-368-11 FILM 0.0047uF 5% 50V
C474 1-137-372-11 FILM 0.022uF 5% 50V
< CONNECTOR >
CNS404 1-770-399-11 HOUSING, CONNECTOR (PC BOARD) 6P
< RESISTOR >
R420 1-249-415-11 CARBON 680 5% 1/4W
R421 1-249-431-11 CARBON 15K 5% 1/4W
R422 1-249-422-11 CARBON 2.7K 5% 1/4W
R423 1-247-903-00 CARBON 1M 5% 1/4W
R424 1-247-903-00 CARBON 1M 5% 1/4W
R470 1-249-415-11 CARBON 680 5% 1/4W
R471 1-249-431-11 CARBON 15K 5% 1/4W
R472 1-249-422-11 CARBON 2.7K 5% 1/4W
R473 1-247-903-00 CARBON 1M 5% 1/4W
R474 1-247-903-00 CARBON 1M 5% 1/4W
< VARIABLE RESISTOR >
RV421 1-223-362-11 RES, VAR, CARBON 100K/100K (BASS)
RV422 1-223-363-11 RES, VAR, CARBON 125K/125K (TREBLE)
RV423 1-238-965-21 RES, VAR, CARBON 100K/100K (BALANCE)
************************************************************
1-673-043-11 VOLUME BOARD
**************
< CAPACITOR >
C420 1-162-207-31 CERAMIC 22PF 5% 50V
C425 1-126-795-11 ELECT 10uF 20% 25V
C426 1-126-795-11 ELECT 10uF 20% 25V
C430 1-104-942-11 ELECT 1uF 20% 50V
C431 1-104-942-11 ELECT 1uF 20% 50V
C440 1-126-163-11 ELECT 4.7uF 20% 50V
C441 1-126-163-11 ELECT 4.7uF 20% 50V
C442 1-126-163-11 ELECT 4.7uF 20% 50V
C443 1-126-163-11 ELECT 4.7uF 20% 50V
C470 1-162-207-31 CERAMIC 22PF 5% 50V
C475 1-126-795-11 ELECT 10uF 20% 25V
C476 1-126-795-11 ELECT 10uF 20% 25V
< CONNECTOR >
CNP202 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
CNP404 1-770-390-11 PIN, CONNECTOR (PC BOARD) 6P
CNS402 1-568-850-11 CONNECTOR, FFC 7P
CNS403 1-784-733-11 CONNECTOR, FFC 11P
< IC >
IC404 8-759-636-74 IC M5218AP-22
< RESISTOR >
R425 1-249-429-11 CARBON 10K 5% 1/4W
R426 1-249-439-11 CARBON 68K 5% 1/4W
R427 1-249-417-11 CARBON 1K 5% 1/4W
R430 1-249-437-11 CARBON 47K 5% 1/4W
R475 1-249-429-11 CARBON 10K 5% 1/4W
R476 1-249-439-11 CARBON 68K 5% 1/4W
R477 1-249-417-11 CARBON 1K 5% 1/4W
R480 1-249-437-11 CARBON 47K 5% 1/4W
< VARIABLE RESISTOR >
RV404 1-225-768-11 RES, VAR, CARBON 100K/100X3
(MASTER VOLUME)
************************************************************
MISCELLANEOUS
***************
61 1-765-348-11 WIRE (FLAT TYPE) (27 CORE)
63 1-765-314-11 WIRE (FLAT TYPE) (7 CORE)
64 1-769-941-11 WIRE (FLAT TYPE) (11 CORE)
! 107 1-777-071-21 CORD, POWER (AEP)
! 107 1-790-226-11 CORD, POWER (UK)
! 108 1-526-794-11 OUTLET, AC (AEP)
110 1-693-408-41 TUNER PACK
111 1-773-001-11 WIRE (FLAT TYPE) (15 CORE)
! T901 1-433-719-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
#3 7-685-881-09 SCREW +BVTT 4X8 (S)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-418-294-11 COMMANDER, STANDARD (RM-U303)
1-475-042-11 ADAPTOR (SCART ADAPTOR)
1-501-374-11 ANTENNA, LOOP
1-501-594-11 ANTENNA (FM)
3-866-249-11 INSTRUCTION MANUAL (ENGLISH, FRENCH,
DUTCH, DANISH, SWEDISH)
3-866-249-21 INSTRUCTION MANUAL (GERMAN, SPANISH,
ITALIAN, PORTUGUESE, FINNISH) (AEP)
4-861-643-01 COVER, BATTERY (FOR RM-U303)
-
TONE VOLUME
Sony Corporation
Home Audio Company
9-928-877-11
99E057548-1
Printed in Hungary © 1999. 5
Published by Quality Assurance Dept.
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
STR-DE235
