STR-DG910
Models of area code E2
1)
Minimum RMS Output Power (8 ohms, 20 Hz –
20 kHz, THD 0.09%)
85 W + 85 W
1)
Stereo Mode Output Power (8 ohms, 1 kHz,
THD 1%)
100 W + 100 W
1)
Surround Mode Output Power
2)
(8 ohms, 1 kHz,
THD 10%)
130 W per channel
1)
1) Measured under the following conditions:
Area code Power requirements
US, CND 120 V AC, 60 Hz
AEP, UK 230 V AC, 50 Hz
E2 240 V AC, 50 Hz
2) Reference power output for front, center, surround and
surround back speakers. Depending on the sound field
settings and the source, there may be no sound output.
Frequency response
Analog 10 Hz – 70 kHz
+0.5/–2 dB (with sound
field and equalizer bypassed)
Inputs
Analog Sensitivity: 500 mV/
50 kohms
S/N
3)
: 96 dB
(A, 500 mV
4)
)
Digital (Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
Digital (Optical) S/N: 100 dB
(A, 20 kHz LPF)
Output (Analog)
AUDIO OUT Voltage: 500 mV/10 kohms
SUB WOOFER Voltage: 2 V/1 kohm
Equalizer
Gain levels ±10 dB, 1 dB step
3) INPUT SHORT (with sound field and equalizer
bypassed).
4) Weighted network, input level.
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Models of area code US, CND
With 10-kHz tuning scale: 530 – 1,710 kHz
5)
With 9-kHz tuning scale: 531 – 1,710 kHz
5)
Models of area code AEP, UK
With 9-kHz tuning scale: 531 – 1,602 kHz
Models of area code E2
With 9-kHz tuning scale: 531 – 1,602 kHz
5)
With 10-kHz tuning scale: 530 – 1,610 kHz
5)
Antenna Loop antenna
Intermediate frequency 450 kHz
5) You can change the AM tuning scale to 9 kHz or 10 kHz.
After tuning in any AM station, turn off the receiver. While
holding down TUNING MODE, press ?/1. All preset
stations will be erased when you change the tuning scale.
To reset the scale to 10 kHz (or 9 kHz), repeat the
procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p/75 ohms
COMPONENT VIDEO: Y: 1 Vp-p/75 ohms
PB/CB: 0.7 Vp-p/
75 ohms
PR/CR: 0.7 Vp-p/
75 ohms
80 MHz HD Pass Through
General
Power requirements
Area code Power requirements
US, CND 120 V AC, 60 Hz
AEP, UK 230 V AC, 50/60 Hz
E2 120/220/240 V AC, 50/60 Hz
Power output (DIGITAL MEDIA PORT)
DC OUT 5 V, 700 mA
Power consumption
Area code Power consumption
US 260 W
CND 360 VA
AEP, UK 230 W
E2 270 W
Power consumption (during standby mode)
0.3 W (When “CONTROL”
in VIDEO menu is set to
“CTRL OFF”)
AC outlets
Area code AC outlets
US, CND 2 switched, 120 W/1A MAX
E2 1 switched, 100 W/0.4 A MAX
Dimensions (w/h/d) (Approx.)
430 × 157.5 × 351.5 mm
(17 × 6 1/4 × 13 7/8
inches) including
projecting parts and
controls
Mass (Approx.) 10.6 kg (23 lb 6 oz)
(Except E2)
11.2 kg (24 lb 11 oz) (E2)
Supplied accessories
FM wire antenna (1)
AM loop antenna (1)
Remote commander RM-AAP016 (1) (US, CND)
Remote commander RM-AAP017 (1) (AEP, UK, E2)
R6 (size-AA) batteries (2)
Optimizer microphone ECM-AC2 (1)
Design and specifications are subject to change
without notice.
•Abbreviation
CND : Canadian model
E2 : AC 120 V area in E model
